2.3.9
COM4 Mode Selection Jumper (JP9)
The jumper selects the COM4 ports' DCD and RI mode.
Description
COM4
Jumpers and Connectors
SBC84831 All-In-One Capa Board User's Manual
Function
Jumper Setting
Pin 1=5V
Pin 1=DCD
(Default)
Pin 8=12V
Pin 8=RI
(Default)
15
