◼ Wide range 12–24V DC-in with terminal block
◼ Din-rail mounting
◼
Wall mounting (optional)
◼ Passed CE, FCC, UL, UKCA certification
⚫ O.S. Supported
ICO120-E3350-A/B/C/E supports Windows 10, Windows® 11 and Linux package. For storage
device, ICO120-E3350-A/B/C/E supports one mSATA.
1.2

System Specifications

1.2.1 CPU
⚫ Onboard Intel ® Celeron® N3350 (2-core, 1.1 GHz) processor.
1.2.2 BIOS
⚫ AMI (American Megatrends Inc.) UEFI (Unified Extensible Firmware Interface)
BIOS.
1.2.3 System Memory
⚫ One DDR3L 204-pin SO-DIMM (1.35V) slot.
⚫ Supports 1600MHz max. up to 8GB.
1.2.4 Display
⚫ An HDMI connector supports up to 1920x1200@60Hz
1.2.5 Ethernet Ports
⚫ LAN Chip: Intel Ethernet Controller
Intel I210-IT (wide temperature)
⚫ Two RJ-45 connectors that support 10/100/1000 Base-T Ethernet with 1.5KV magnetic isolated
protection
1.2.6 Storages
⚫ 1 x mSATA.
⚫ 1 x eMMC (optional)
.
