SBC84831 All-In-One Capa Board User's Manual
Primary/Secondary/Third IDE Master/Slave
Select one of the hard disk drives to configure IDE
devices installed in the system by pressing <Enter> for
more options.
SuperIO Configuration
You can use this screen to select options for the SuperIO
Configuration, and change the value of the selected option. A
description of the selected item appears on the right side of the
screen.
Serial Port1 Address
This item specifies the base I/O port address and
Interrupt Request address of serial port 1. The Optimal
setting is 3F8/IRQ4. The Fail-Safe default setting is
Disabled.
Serial Port1 IRQ
This item specifies the IRQ used by the serial port 1.
Serial Port2 Address
This item specifies the base I/O port address and
38
AMI BIOS Setup Utility
