SBC81203 LGA775 SBC User's Manual
1.1

Specifications

® TM
CPU: Intel Core
®
Celeron D processors
System Chipset: Intel
CPU Socket: LGA775
Front-Side Bus: 533/800/1066MHz
BIOS
Award PnP Flash BIOS
System Memory
Two x 240-pin DDR2 DIMM sockets
Maximum up to 4GB DDR2 memory
Support DDR533/667 memory
L2 Cache: integrated in CPU
IDE Interface
One IDE connector and up to two IDE devices, Ultra DMA
ATA33/66/100 supported
Onboard Multi-I/O
Parallel Port: one bi-directional with ECP/EPP/SPP support
Serial Port: one for RS-232 (COM1) and one port for
RS-232/422/485 (COM2)
Floppy controller: supports two drives (1.44MB for each)
USB Interface
Six USB ports compliant with USB Spec. Rev. 2.0
VGA Controller
Chipset Integrated VGA Controller and Supports up to
2048x1536 at 75 Hz resolution on non-interlaced CRT
monitors
Ethernet
The LAN1/LAN2: Intel
2
®
2 Duo, Pentium D, Pentium
®
945G & ICH7R
®
82573L Ethernet controller supports
®
4 and
Introduction
