SBC84831 All-In-One Capa Board User's Manual
2.3.1
LCD Voltage Selection Jumper (JP1)
The board supports +3.3V or +5V flat panel displays. Configure the
jumper JP1 to the appropriate voltage of the flat panel.
Description
LCD Voltage
Selection
2.3.2 Audio Output Jumper (JP2)
This jumper is to select the Audio output.
Description Function
Audio Output
10
Function
Jumper Setting
3.3V
(Default)
5V
Jumper Setting
Line Out
(Default)
Speaker
Out
Jumpers and Connectors
