2.3.7
COM6 Mode Selection Jumper (JP7)
The jumper selects the CN6 COM6 ports' DCD and RI mode.
Description
COM6
Jumpers and Connectors
SBC84831 All-In-One Capa Board User's Manual
Function
Jumper Setting
CN6 Pin 11=5V
CN6
Pin 11=DCD
(Default)
CN6 Pin 18=12V
CN6 Pin 18=RI
(Default)
13
