Chapter 5 Media Load
Cut-Off, cont.
3
Turn the printhead lift lever to "Load" posi-
5a
Fit a new roll of media on the supply hub and
push the roll inwards as far as it will go.
32
tion.
4
Remove any empty core from the media
5b
In case of a media roll with a 76.2 mm (3
inches) core, fi rst fi t the adapter on the media
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
supply hub.
supply hub.
