Chapter 5 Media Load
Peel-Off, cont.
10
Route the liner around the platen roller and
the tear bar, then rearwards under the print
12
Turn the printhead lift lever to "Print" posi-
38
unit.
tion.
11
Secure the liner to the takeup hub with the clip
(1) and wind up some of the liner so it becomes
13
Adjust the green edge guide so the media is
guided with a minimum of play.
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
2.
tight (2).
