Chapter 3 Installation
Media Com-
partment, cont.
Ribbon Supply Hub
Ribbon Rewind Hub
Thermal Printhead
Tear Bar
Cutter
(option)
Printhead Lift Lever
20
The illustration below shows an EasyCoder 501 S with some options
installed. There are more options that are not illustrated here. Refer
the Appendix 1 for complete lists of standard features and options
for the EasyCoder 501 S.
Media Supply Hub
Shaft with
Edge Guide
Liner Takeup
and Guide Shaft
(option)
Batch Takeup
Guide (option)
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
External Supply Guides
and Edge Guide
(option)
3-inch Adapter
Media Roll
Retainer
(option)
