Chapter 9 Intermec Shell Startup Program
Terminal Setup, cont.

Setup Parameters

Note:
After you have pressed CR, a series of
additional prompts will appear where
you can adjust the LSS following the
same principles as described in Chapter
13 "Adjustments".
82
The displayed values refer to the default setup of an 8 dots/mm
EasyCoder 501 S.
----------------
SETUP FROM
TERMINAL
----------------
Reading printer setup, please wait.
If no change, press ENTER
To end terminal setup: enter QUIT (Q), or QUIT and SAVE (S)
CONTRAST,5
New value: (0-10) :
UART1,BAUDRATE,9600
New value: (1:300 2:600 3:1200 4:2400 5:4800 6:9600 7:19200) :
UART1,PARITY,NONE
New value: (1:NONE 2:EVEN 3:ODD 4:MARK 5:SPACE) :
UART1,CHAR LENGTH,7
New value: (1:7 2:8) :
UART1,STOPBITS,2
New value: (1:1 2:2) :
UART1,FLOWCONTROL,RTS/CTS,DISABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,FLOWCONTROL,ENQ/ACK,DISABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,FLOWCONTROL,XON/XOFF,DATA FROM HOST,ENABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,FLOWCONTROL,XON/XOFF,DATA TO HOST,ENABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,NEW LINE,CR/LF
New value: (1:CR/LF 2:LF 3:CR) :
DETECTION,LSS ADJUST,80
New value: (0-127) Press F <CR> for testfeed. Press <CR> when OK :
DETECTION,FEEDADJ,STARTADJ,0
New value: (-9999 thru +9999) :
DETECTION,FEEDADJ,STOPADJ,0
New value: (-9999 thru +9999) :
MEDIA SIZE,XSTART,0
New value: (0-999) :
MEDIA SIZE,WIDTH,832
New value: (0-9999) :
MEDIA SIZE,LENGTH,1200
New value: (0-9999) :
MEDIA TYPE,LABEL (w GAPS)
New value: (1:LABEL (w GAPS) 2:TICKET (w MARK) 3:TICKET (w GAPS))
(4:FIX LENGTH STRIP 5:VAR LENGTH STRIP) :
