Chapter 7 Setting Up the Printer
Setup Parameters, cont.
Service, cont.
66
• Thermal Transfer Printing
The recommended standard "Paper Type" options for thermal
transfer printing are shown in the table below in order from the
lowest printing energy at the top to the highest at the bottom of the
table. If you are not sure how to set the "Paper Type" parameter,
start with the lowest energy setting (UBI GP 11) and work your
way up towards the highest (UBI HR 30), until you achieve the best
printout quality. Use of higher "Paper Type" levels than listed for
each ribbon type should be avoided, but lower levels are preferred
whenever an acceptable printout quality is obtained.
Option Ribbon Type
UBI GP 11 General Purpose/
UBI GP 10 Standard
UBI HP 21 High Performance/ High Gloss White
1
UBI HP 20 Premium
UBI HR 31 High Resistance/
UBI HR 30 Super Premium
1 /. Also try UBI HP 21.
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
Face Material Energy
Matte Coated Low
Vellum/Uncoated
Matte Coated
Polyester Gloss
Polyester Matte High
