Appendix 2 Media Specifi cations

Media Roll Size

110
Core
Diameters: 38-40 mm (1.5 inches) or 76.2 mm (3 inches)
Width: Must not protrude outside the media.
The media must be wound up on the core in such a way that the
printer can pull the end free.
Roll
Max. diameter (internal roll):
Max. width:
Min. width:
Max. web thickness:
The maximum recommended media thickness is 175µm. Thicker
media may be used, but print quality will be reduced. The stiffness
is also important and must be balanced against thickness to maintain
print quality.
Any external media supply should be well protected against sand,
grit, etc. Even very small but hard particles may cause severe
harm to the printhead.
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
205 mm (8.00 inches)
120 mm (4.72 inches)
25.4 mm (1.00 inches)
175 µm (0.007 inches)
Caution!
