2.5-inch HDD/SSD configurations

7.5.1

Overview of configurations

7.5.1.1

Configuration with up to four HDD/SSD modules

Figure 69: Configuration with up to four 2.5-inch HDDs/SSDs
Position Logical drive
number
[0] 0
[1] 1
[2] 2
[3] 3
Configuration with the 4x 2.5-inch PCIe SSD backplane
Position Logical drive
number
[0] ‐
[1] ‐
[2] ‐
[3] ‐
150
56.
58.
ServerView RAID Manager display
name
Vendor Product (0)
Vendor Product (1)
Vendor Product (2)
Vendor Product (3)
ServerView RAID Manager display
name
Vendor Product (0)
Vendor Product (1)
Vendor Product (2)
Vendor Product (3)
