Preparations for use

Instrument with stand (option)

Setting the working height of the support unit

CAUTION
R019
CAUTION
R081
CAUTION
R099
Page 38
The required working height of the support unit can be set by the locking ring
(3) on the column.
Risk of injury caused by lowering of the support unit!
If the clamping screws on the locking ring are not tightened adequately, the
support unit may slip on the stand column, which may lead to injuries.
• Always make sure that the clamping screws on the locking ring have
been tightened before using the colposcope.
Risk of injury caused by changing the working height!
When the friction knob for rotational motion is released, the support unit
may inadvertently be pulled off upwards.
• Proceed as follows to change the working height of the support unit.
To lower the support unit:
• Firmly tighten the friction knob for rotational motion (2).
• Loosen clamping screws (3) on the locking ring.
• Position locking ring at the new height level and firmly tighten securing
screws (3).
• Hold the support unit (1) with your hand and release the friction knob for
rotational motion (2).
• Carefully lower the support unit (1) until it reaches the locking ring.
To raise the support unit:
Risk of injury caused by excessively high working height!
If the working height is set too high, the support unit may topple from the
stand column and injure you.
• Do not exceed the maximum working height of the support unit, which
is reached when the upper edge of the stand column is level with the up-
per edge of the carrier arm.
• Release the friction knob for rotational motion (2) and carefully move the
support unit (1) upwards along the support column.
