Programming Manual
3.2

The buttons

TEST Initialises the test phase and activates all the control panel LEDs.
Silences the control panel buzzer. The buzzer will be unsilenced automatically if
BUZZER
another event occurs. RESET operations also silence the buzzer.
If this button is pressed during Pre-alarm status, it will activate a pre-set alarm delay.
INVESTIGATE
If this button is pressed once, it will silence the NAC outputs, fault output and all
SILENCE
'Silenceable' outputs. If this button is pressed again, it will toggle (undo) the silence
command.
RESET Resets the control panel (clears alarms).
Activates the "Evacuate" phase. If this button is pressed by a building occupant
EVACUATE
during pre-alarm status (Level 1- no access code or key required), it will generate an
instant alarm.
If this button is pressed after valide key or code entry (Level 2), it will generate an
instant alarm regardless of the system status.
3.3

The LED

DESCRIPTION COLOUR
ALARM Red
PRE-ALARM Red
DISABLED Yellow
TEST Yellow
NIGHT Yellow
In Service Green
The SmartLoop control panel
Table 1: The status LEDs
STATUS Group
The control panel is in alarm status. This LED goes On to signal the following
conditions:
- Alarm status of a point defined as an "Alarm" point
- "Evacuate" phase running (triggered by the EVACUATE button on the control
panel or a connected Repeater panel)
- "Evacuate" phase running (triggered by the EVACUATE button on a Network
control panel or Network Repeater panel)
The control panel is in pre-alarm status. This LED goes On to signal the alarm
status of a point programmed as an "Alarm" point with the "Pre-alarm"
attribute.
If this LED is On, at least one of the system objects (point, zone, output,
communicator, etc.) has been disabled.
If this LED is On, at least one of the system objects (point, zone, output,
communicator, etc.) is in test status. A zone test affects all the points of the
zone concerned.
If this LED is On, the control panel is operating in Night mode. During Day
mode, the control panel can generate pre-alarms and hold silence status for an
unlimited time. During Night mode, the control panel can hold silence status for
the pre-set time only. During Night mode, the control panel cannot generate
pre-alarms as this function is disabled.
If this LED is On, the control panel is powered and working.
MEANING
