Programming Manual
You (the installer) can choose the method you use for addressing the loop devices. You can assign the
addresses manually (refer to Appendix B and Appendix C in the Installation Manual) and then enroll
them on the control panel, or command the control panel to assign the addresses automatically (this
method is for capable loop protocols only).
The auto-configuring and auto-addressing functions greatly simplify the configuration process of
difficult systems.
AUTO Configuration procedure:
1. Set the parameters of each loop.
2. Assign addresses manually to the devices of each loop (if necessary).
3. Configure the loops, repeaters, I/O expansion boards, telephone dialler and network.
4. Connect the computer and allow it to acquire the data then proceed with the programming phase.
7.2.1 Setting the loop parameters
Specify the type of loop wiring and protocol to be used (in accordance with the installed devices).
Refer to paragraph 17.1 Defining loop typology.
7.2.2 Auto-configuring loops
FROM PANEL
<any key>,
or <any key>,
There are three ways of configuring the control panel:
ACQUIRE DEVICES
ADDRESS NEW
DEVICES
RE-ADDRESS ALL
Choose the method which is most suited to the particular needs of the system you are working on.
Lo op N .
AC QUIRE DEVI CES
AD DRESS NEW DEV.
RE -ADDRESS A LL
Lo op configu ration in progress .. .
61 % --- ---
Lo op n°. x
De tectors
OU T Module
So unders
Initialising the configuration/programming from panel
8 Programming, <code>, 1 Configuration, 2 Modify
Configuration, 1 AUTO Configuration , 2 Loop,
8 <code> 1 2 1 2
The control panel learns the manually-assigned addresses of the installed
devices, however, it will not acknowledge any devices with factory-set addresses.
Physical removal of any devices from the loop results in their automatic deletion
from the configuration.
The control panel will verify the presence of new devices (address=255) and will
assign addresses automatically, starting from the first free address available.
It will then enroll the new devices in the same way as the Acquired devices
function.
The control panel will assign address 255 to all the loop devices, re-address them
in increasing order and then enroll the new addresses.
1 2 3 4 5 6 7 8
: . . . . . . . .
: . . . . . . . .
: . . . . . . . .
--- --- - --
<L oop Descript ion>
:xxx IN Module
:xxx IN/OUT Mod.
:xxx Call Poin ts
Press keys
through the screens.
Press keys
deselect ('.') the function on each of the 8
loops.
Press key
The procedure may take several minutes.
--- ---
A progress
advancement of each phase.
On completion a report showing the
devices enrolled on each loop appears.
:xxx
:xxx
Press keys
:xxx
through the configured loops.
and to navigate
and to select ('+') or
to confirm.
bar will indicate
and to navigate
the
