How to use the display and keypad

All SmartLoop models, except for the SmartLoop2080/S and SmartLoop1010/S, allow users to
operate the system from the control panel keypad. All control panels allow users to operate the
system from connected SmartLetUSee/LCD Repeater panels.
Most of the conventions relating to the operating principles of following menu screens (navigating
method, space, changes, etc.), are common to all menu screens.
Attention:
The procedures described in this section will not be repeated in other parts of this
manual, however, any exceptions to this procedure will be described.
4.1

Selecting an option

This section describes how to navigate through the menus and which options to select:
FROM PANEL
<any key>,
or <any key>,
4.1.1 Navigating through the menu
Sm artLoop System Run ning
NO Alarm
NO Fault
01 /01/00 00: 45 AM Sat
1 Rea d Log
2 Check Det ectors sta te
3 Panel Set tings
4 Disabl e
4.1.2 Entering the number of menu options
5 Dialler Settin gs
6 Printer S ettings
7 Maintenan ce
8 Program ming
14
8 Programming, <code>, 1 Configuration, 2 Modify
Configuration, 1 AUTO Configuration , 2 Loop,
8 <code> 1 2 1 2
Press any key to access the Main menu.
Press keys
Press key
menu or screen).
An ' ' indicates that the menu options continue after the
last line.
Press ESC to step back to the previous level.
If you already know the number of a menu option, press
the corresponding number/s on the keypad. For example:
a. 8 Programming
b. Enter the Access Code
c. 1 Configuration
d. 1 View Configuration
e. 3 Repeater
Type in: "8 <code> 1 1 3"
and to scroll the menu.
to select the menu option (to access another
