3.2

Function buttons and LEDs

The LEDs on the sides and below the screen provide visual signals which indicate the general status of the system,
whereas the function buttons allow fast execution of all the main operations.
The key permits level 1 (public level) to pass to level 2 (supervisor level). When turned clockwise the key will generate a
pulse which places the control panel in level 2 status. The control panel will return to level 1 if no buttons are pushed
within 20 seconds.
[A]
Touchscreen display
[B]
Status LED
[C]
Function buttons
LED and multiple-alarm
[D]
[E]
Access-key slot
Zone status LEDs
[F]
(only on certain models)
Extinction channel status LED
[G]
(only on certain models)
Status LED
Alarm
Fault
ON
CPU Fault
Disabled
Test
10
button
Colour
Red
A fault (of any type) is present on the
Yellow
The details of any active faults are
Green
The CPU of the control panel is out
microcontrollers inside the cabinet
Yellow
If the fault does not clear when the
Reset button is pressed, contact the
technical-assistance service.
Yellow
elements has been disabled.
Yellow
elements has been put in test mode.
F B
01 02 03 04 05 01 02 03 04 05
06 07 08 09 10 06 07 08 09 10
11 12 13 14 15 11 12 13 14 15
16 17 18 19 20 16 17 18 19 20
21 22 23 24 25 21 22 23 24 25
26 27 28 29 30 26 27 28 29 30
TEST TEST
On solid
Fire alarm running.
system.
shown on the screen.
The system is functioning.
of service or one of the
does not respond.
One or more of the system
One or more of the system
Fire detection and extinguishant system
G
C
A
D
Flashing
Fire alarm memory.
Fault memory.
A fault has been solved.
CPU fault memory.
The control panel CPU has reset and
restarted.
E
User interface
