Programming Manual
Re peater
in Configura tion : YN
<R epeater De scription>
7.4.4 Viewing I/O expansion boards
FROM PANEL
<any key>,
or <any key>,
I/ O
in Configura tion : YES
7.5

Manual configuration

Manual enrolling from the control panel allows you to work on the configuration parameters of the
loops, Repeaters, I/O expansion boards and the telephone dialler board and on the parameters of the
loop devices.
7.5.1 Adding/Deleting Loops and data changes
FROM PANEL
<any key>,
or <any key>,
1 Loo p 1
2 Loop 2
3 Loop 3
4 Loop 4
1 Loo p Paramete rs
2 Add/Modif y Point
3 Remove Po int
Note:
For a full description of the parameters, refer to paragraph 17.1 Defining loop typology.
7.5.2 Add/Change device
FROM PANEL
<any key>,
or <any key>,
Initialising the configuration/programming from panel
n
8 Programming, <code>, 1 Configuration, 1 View
configuration, 4 Optional cards,
8 <code> 1 1 4
8 Programming, <code>, 1 Configuration, 2 Modify
Configuration, 2 Manual Configuration, 1 Loop,
8 <code> 1 2 2 1
<Loop De scription>
<Lo op Descript ion>
N ot avaible
N ot avaible
8 Programming, <code>, 1 Configuration, 2 Modify
Configuration, 2 Manual Configuration, 1 Loop,
x Loop, 2 Add/Modify Point,
8 <code> 1 2 2 1 x 2
Press keys and
the loops.
Press keys and
through the loops.
Press key on the loop to be configured/
changed.
Press key on Loop Parameters to
access the loop configuration phase.
to navigate through
to navigate
23
