Programming Manual

Programming the NAC outputs

19.1

The intermittent signals of the NAC Outputs

FROM COMPUTER
Go to SmartLoop System, Control panel x, NAC, System Programming, Patterns
The NAC outputs can be activated by up to four different intermittent signal sequences of one-second
pulses that produce different audible signals depending on the type of signal or the zones they are
coming from.
The sequence can last up to 16 seconds, the first sequence is continuous and non-configurable.
19.1.1 Procedure
1. Assign a description the intermittent signal sequence.
2. Specify the duration.
3. Double-click to enable or disable the intermittent signal.
FROM PANEL
Not available.
19.2

The NAC outputs

FROM COMPUTER
Go to SmartLoop System, Control panel x, NAC, System Programming, NAC Outputs
The control panel motherboard provides three NAC outputs (refer to the Installation Manual paragraph
4.1 The motherboard)
A NAC output can be activated either by a control panel condition (e.g. Reset, Silence, etc.), or by a
group (maximum 3) or signals coming from the control panel, zones and devices. Each activation can
be associated with up to four different intermittent signals, of which one is continuous (refer to
paragraph 19.1 The intermittent signals of the NAC Outputs).
19.2.1 Parameters
Type
Pulse Lenght
Output NOT silenceable
Inverted Output
Activate Outputs
Groups that activate the
output
Signals that activate the
output
FROM PANEL
Not available.
Programming the NAC outputs
that can be connected to external Early Warning devices, (e.g. Sirens).
Pulse or bistable. If you select "Pulse", you must specify the pulse length.
The output will remain active even after the control panel has executed a
Silence command.
The output is normally active, and deactivates when the activating conditions
occur.
The output will be activated by Reset, Silence or Investigation commands or
Night mode.
The output will be activated with the indicated intermittent signals when the
specified group activates.
The output will be activated with the indicated intermittent signals when it
receives the specified signals from the control panel, zones or a device.
Chapter 19
