Programming Manual
Secondary Group of zones whose signals can be activated by the device (as input), or that can activate
Zones the signals of the device (as output).
Table 6: Signals Section activated by the device (as input)
To the Control panel signals activated by the device. The available signals depend on the Activation
control panel Type you select for the device.
To the zones Signals that will be activated on ALL the control panel zones. The available signals depend on
the Activation Type you select for the device (for example, a module, that when activated
generates "Close Fire door" signals on the ENTIRE system).
To Signals that will be activated on the secondary zone group of the device. The available signals
secondary depend on the Activation Type you select for the device (for example, a detector that goes
zones into alarm status and activates alarm signals on all the zones on the floor).
To the Signals that will be activated on the zone the device belongs to (for example, a detector that
device zone goes into alarm status and in turn activates alarm signals on the zone it belongs to).
To the Each device can activate up to three different groups. In this section, as well as selecting the
groups groups that will be activated, you can also select the statuses of the device that activate the
groups. The available statuses depend on the Activation Type you select for the device.
Table 7: Signals Section that activate the device (output R)
From the Control panel signals that activate the device output.
Control panel
From the Signals from the zone the device belongs to that activate the device output.
device zone
From the Signals of the secondary zone group associated with the device that activate its output (for
secondary example, if you select the pre-alarm signal of the secondary outputs, and a zone that
zones belongs to the secondary zone group goes into pre- alarm status, the device output will
activate).
From other The output will activate, following one or more statuses of a specific device that is
zones programmed to follow. The available statuses depend on the Activation Type you select for
the device to follow.
From the The output will activate, if one or more groups switch to ON status. The groups that can
groups activate the output are the same as those selected in the Signals Section that are activated
by the device (as input).
You can program a device to activate itself when the device input activates, the output will
replicate the activation).
From special The output activates following particular control panel statuses.
conditions
Activation If the R output is a pulse output, this is the activation time.
Time
FROM PANEL
<any key>,
or <any key>,
001 < Dev. Type> <Dev. Desc ription>
0 02 <Dev. T ype> <Dev. Descriptio n>
0 03 <Dev. T ype> <Dev. Descriptio n>
0 04 <Dev. T ype> <Dev. Descriptio n>
Loop device settings
8 Programming, <code>, 2 POINT Programming, x Loop,
yyy point,
8 <code> 2 x yyy
Press keys and
type in the device number.
Press to confirm.
to scroll the list or
