Maintenance operations

The following maintenance operations can be implemented by installers or authorized technicians only
(Level 3) who can:
1. By means of a screw driver or similar tool, remove the screws and open the control panel cabinet.
2. Connect the programming jumper J2 PROGRAM.
3. Type in a valid access code: the control panel will allow access to the maintenance functions.
27.1

Testing/Enabling a zone

FROM COMPUTER
Not available.
During zone Test status, detectors and other signaling devices associated with the zone will be unable
to generate faults, alarms or signals. Activation of a detector during zone test status will light its LED,
which will reset automatically. This feature allows operators to test the system devices without moving
away from the panel.
FROM PANEL
<any key>,
or <any key>,
Zo ne yyy <
S TATUS :
= S elect Zone
Note:
Testing/Enabling a zone involves testing/enabling all the zone points (detectors).
27.2

Testing/Enabling a detector

FROM COMPUTER
Not available.
During test status, the detector will be unable to generate faults, alarms or signals. Activation of a
detector during test status will light its LED, which will reset automatically. This feature allows
operators to test the system devices without moving away from the panel.
FROM PANEL
<any key>,
or <any key>,
Po int x/yyy < Descrip tion >
Ty pe :
S TATUS :
= Select Point
66
7 Maintenance, <code>, 1 Zone in TEST Mode,
7 <code> 1
Zon e Desc ription >
_o rmal Mode
= Test ON/ OFF
7 Maintenance, <code>, 2 Point in TEST Mode, x Loop x,
yyy detector,
7 <code> 2 x yyy
< Device Type >
_o rmal Mode
= Test ON /OFF
Chapter 27
Press keys and to view the data of
the adjacent zones.
Press ESC to confirm the entry and step
back to the previous menu.
Press keys and to view the adjacent
detectors.
Press ESC to confirm the entry and step
back to the previous menu.
