Power supply settings
16.1
How to program the power supply
FROM COMPUTER
Go to SmartLoop System, Control panel x, Power supply, System Programming
This option will allow you to set the operating parameters of the control panel power-supply and
enquirie regarding the minimum battery capacity required to satisfy the system needs during mains
failure (specified in hours).
16.1.1 Parameters
Mains fault signal
delay
After Mains restore
disable battery test
Battery capacity
calculation
Minimum battery
size needed
FROM PANEL
Not available.
48
This is a delay between the start of a mains failure event and the respective fault
signal. This delay avoids unnecessary signaling of brief 'Mains failure' events.
This is the period between mains electricity restoral (during which time the
battery test will be inhibited) and the moment the control panel starts monitoring
the battery efficiency again. Used to suspend the periodic battery-efficiency test,
that may fail if the batteries are recharging.
Data the operator must enter in order to allow the system to calculate the
minimum battery requirements.
Stand by Autonomy
Alarm Autonomy
Additional loads in stand by
Additional loads in Alarm
Battery efficiency factor
Select Calculate to ask the system to calculate the minimum capacity
requirements, and the typ e of battery to install.
Chapter 16
This is the power autonomy required by the
system in the event of mains failure when the
control panel is in standby status.
This is the battery autonomy required by the
system in the event of mains failure when the
control panel is in Alarm status, once the
Standby autonomy has run out.
This is the current consumption of external
loads (devices connected to the AUX and AUX-
R outputs) when the control panel is in
standby status.
This is the current consumption of external
loads (devices connected to the AUX and AUX-
R outputs) when the control panel is in Alarm
status.
This is the co-efficient that represents the
battery efficiency status (e.g. New
battery=1).
Programming Manual
Power supply settings
