Remove the speakers (3). The speakers are available using spare part number 452310-001
23.
Reverse this procedure to install the display bezel, camera module, display inverter, display panel, and
speakers.

Hard drive

NOTE:
All hard drive spare part kits include a hard drive bracket.
Description
320-GB, 5400-rpm
250-GB, 5400-rpm
200-GB, 4200-rpm
160-GB, 5400-rpm
120-GB, 7200-rpm
120-GB, 5400-rpm
100-GB, 7200-rpm
Before removing the hard drive, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the hard drive:
Loosen the six black Phillips PM2.0×5.0 captive screws (1) that secure the hard drive bay cover to
1.
the computer.
42
Chapter 4 Removal and replacement procedures
Battery on page
36).
Spare part number
459611-001
454605-001
448155-001
448154-001
448152-001
448153-001
452313-001
