HP Pavilion HDX Maintenance And Service Manual page 85

Desription
X7900 2.8-GHz processor, 4-MB L2 cache
X7800 2.6-GHz processor, 4-MB L2 cache
Intel Core 2 Duo processors (800-MHz FSB, 35-W):
T9500 2.6-GHz processor, 6-MB L2 cache
T9300 2.5-Ghz processor, 6-MB L2 cache
T8300 2.4-GHz processor, 3-MB L2 cache
T8100 2.1-GHz processor, 3-MB L2 cache
T7700 2.4-GHz processor, 4-MB L2 cache
T7500 2.2-GHz processor, 4-MB L2 cache
T7300 2.0-GHz processor, 4-MB L2 cache
T7250 2.0-GHz processor, 4-MB L2 cache
T7100 1.8-GHz processor, 4-MB L2 cache
Before removing the processor, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the following components:
5.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover (see
e.
Top cover (see
f.
Subwoofer (see
g.
System board (see
h.
Processor heat sink (see
i.
Remove the processor:
Turn the processor locking screw (1) one-half turn counterclockwise until you hear a click.
1.
78 Chapter 4 Removal and replacement procedures
Battery on page 36).
Hard drive on page 42)
Optical drive on page
Keyboard on page 50)
Hinge cover on page
Rear cover on page 53)
Top cover on page 55)
Subwoofer on page 67)
System board on page
Processor heat sink on page
49)
52)
70)
75)
Spare part number
453908-001
455738-001 and
452327-001
459609-001
459608-001
459607-001
459606-001
448148-001
448147-001
448146-001
456965-001
448149-001
