HP Pavilion HDX Entertainment Notebook PC
Maintenance and Service Guide

Advertisement

Table of Contents
loading

  Related Manuals for HP Pavilion HDX9000 - Entertainment Notebook PC

  Summary of Contents for HP Pavilion HDX9000 - Entertainment Notebook PC

  • Page 1 HP Pavilion HDX Entertainment Notebook PC Maintenance and Service Guide...
  • Page 2 © Copyright 2007 Hewlett-Packard Development Company, L.P. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft,...
  • Page 3 Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.
  • Page 4 Safety warning notice...
  • Page 5: Table Of Contents

    Table of contents 1 Product description 2 External component identification Top components ........................6 Display and top components ..................6 Top-left buttons and lights ................... 7 Top-right buttons, lights, and fingerprint reader ............. 9 TouchPad ....................... 10 Keys ............................. 11 Front components ........................
  • Page 6 Unknown user password ..................36 Component replacement procedures ..................37 Serial number ......................37 Battery ........................38 Computer feet ......................39 Display assembly internal components ............... 40 Hard drive ......................45 WLAN module ......................47 TV tuner module ...................... 49 Memory module ......................
  • Page 7 6 Specifications Computer specifications ......................98 20.1-inch, WUXGA display specifications ................99 20.1-inch WSXGA+ display specifications ................100 Hard drive specifications ...................... 101 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive specifications ......102 System DMA specifications ....................103 System interrupt specifications ....................104 System I/O address specifications ..................
  • Page 8 Universal Serial Bus ......................141 10 Power cord set requirements Requirements for all countries or regions ................. 142 Requirements for specific countries or regions ................143 11 Recycling Battery ..........................144 Display ..........................144 Index ..........................150 viii...
  • Page 9: Product Description

    Product description Category Description Product Name HP Pavilion HDX Entertainment Notebook PC Processors Intel® Core™ 2 Extreme processors (4-MB L2 cache, 800-MHz front side bus (FSB), 44-W): X7900 2.8-GHz processor X7800 2.6-GHz processor Intel® Core™ Duo processors (4-MB L2 cache, 800-MHz FSB, 35-W): T7700 2.4-GHz processor T7500 2.2-GHz processor T7300 2.0-GHz processor...
  • Page 10 Category Description Dual hard drive configurations: 400-GB, 4200-rpm (200 GB × 2) ● 320-GB, 5400-rpm (160 GB × 2) ● 280-GB, 5400-rpm (160 GB + 120 GB) ● 240-GB, 5400-rpm (120 GB + 120 MB) ● 200-GB, 7200-rpm (100 GB × 2) ●...
  • Page 11 Category Description Intel PRO wireless 4965 a/b/g with 2 WLAN antennae built into the display assembly + Bluetooth® Intel PRO wireless 4965 a/b/g/n with 3 WLAN antennae built into the display assembly + Bluetooth Intel PRO wireless 3945 a/b/g with 2 WLAN antennae built into the display assembly + Bluetooth Integrated TV tuner options Integrated NTSC/ATSC hybrid TV tuner (in Canada and the United States)
  • Page 12 Category Description S-Video-out (including composite video support) via docking only USB (4) Remote control The remote control is docked into the keyboard deck. The remote control can be ejected by pressing the remote control eject button. The remote control can also be locked onto the computer.
  • Page 13 Category Description Video (in the United States)/Y (in Europe, the Middle East, and Africa) ● Zoom (in the United States)/B (in Europe, the Middle East, and Africa) ● Docking Expansion port 3 supports the HP xb3000 Notebook Expansion Base and HP Notebook QuickDock (does not support power via dock) Keyboard/pointing devices 14.39-inch full-size keyboard with separate numeric keypad...
  • Page 14: External Component Identification

    External component identification Top components Display and top components Item Component Description Speakers (4) Produce sound. Internal microphones (2) (select models only) Record sound. NOTE: If there is a microphone icon next to each microphone opening, the computer has internal microphones.
  • Page 15: Top-Left Buttons And Lights

    Item Component Description HP Webcam rotator Tilts the camera vertically. Internal display switch Turns off the display if the display is closed while the computer is on. Top-left buttons and lights Item Component Description Power button* ● When the computer is off, press the button to turn on the computer.
  • Page 16 Item Component Description NOTE: If the computer has been set up to require a logon password, you may be asked to log on to Windows. QuickPlay or DVDPlay opens after you log on. Refer to the QuickPlay or DVDPlay software Help for more information. DVD button Opens the DVD playback feature of the QuickPlay program.
  • Page 17: Top-Right Buttons, Lights, And Fingerprint Reader

    Top-right buttons, lights, and fingerprint reader Item Component Function Fingerprint reader Allows a fingerprint logon to Windows, instead of a password logon. Wireless button Turns the wireless feature on or off, but does not create a wireless connection. NOTE: To establish a wireless connection, a wireless network must already be set up.
  • Page 18: Touchpad

    Item Component Function (14) Treble light (select models only) On: The treble volume function is on. (15) Bass light (select models only) On: The bass volume function is on. (16) Treble/bass button (select models only) Alternates between treble and bass volume controls. (17) Num lock light On: Num lock is on or the embedded numeric keypad is...
  • Page 19: Keys

    Keys Item Component Description Displays system information when pressed in combination with the key. Function keys Execute frequently used system functions when pressed in combination with the key. Integrated numeric keypad keys Can be used like the keys on an external numeric keypad. Executes frequently used system functions when pressed in combination with a function key or the key.
  • Page 20: Front Components

    Front components Item Component Function Power light ● On: The computer is on. Blinking: The computer is in the Sleep state. ● Off: The computer is off or in Hibernation. ● Battery light On: A battery is charging. ● Blinking: A battery that is the only available power ●...
  • Page 21: Rear Components

    Rear components Rear left-side components Item Component Description Vent Enables airflow to cool internal components. NOTE: The computer fan starts up automatically to cool internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation. Infrared (IR) emitter jack Connects the computer to your cable or satellite set-top box.
  • Page 22: Rear Right-Side Components

    Rear right-side components Item Component Description Left- and right-side analog channel output jack Connects optional audio speakers for left- and right-side audio output. Rear left- and right-side analog channel output jack Connects optional audio speakers for rear left- and right-side audio output.
  • Page 23: Right-Side Components

    Right-side components Item Component Function USB ports (2) Connect optional USB devices. Optical drive Reads optical discs, and, on select models, also writes to optical discs. Optical drive light Blinking: The optical drive is being accessed. Security cable slot Attaches an optional security cable to the computer. NOTE: The security cable is designed to act as a deterrent, but it may not prevent the computer from being...
  • Page 24: Left-Side Components

    Left-side components Item Component Function USB ports (2) Connect optional USB devices. RJ-45 (network) jack Connects a network cable. Expansion port 3 Connects the computer to an optional docking device or expansion product. NOTE: The computer has only one expansion port. The term expansion port 3 describes the type of expansion port.
  • Page 25: Bottom Components

    Bottom components Item Component Function Hard drive bay Holds the hard drives. NOTE: Depending on the computer model, the computer may have 1 or 2 hard drives. Vents (5) Enable airflow to cool internal components. NOTE: The computer fans start up automatically to cool internal components and prevent overheating.
  • Page 26: Illustrated Parts Catalog

    Illustrated parts catalog Serial number location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer. Chapter 3 Illustrated parts catalog...
  • Page 27: Computer Major Components

    Computer major components Computer major components...
  • Page 28 Item Description Spare part number Display assemblies (include wireless antenna transceivers and cables, camera module and cable, speakers, and microphones and cables) 20.1-inch, WSXGA, TFT with BrightView 452299-001 20.1-inch, WUXGA, TFT 452300-001 NOTE: Display assembly components on page 23 for more information on display assembly spare part numbers.
  • Page 29 Item Description Spare part number (14) RTC battery 452319-001 (15) Front USB board (includes cable) 452314-001 (16) Bluetooth module 398393-002 NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is available in the Cable Kit, spare part number 448169-001. (17) Video board fan 448163-001...
  • Page 30 Item Description Spare part number Intel 802.11a/b/g WLAN modules: For use in Antigua & Barbuda, Argentina, Australia, the Bahamas, Barbados, Brunei, 452063-001 ● Canada, Chile, the Dominican Republic, Guam, Guatemala, Hong Kong, India, Indonesia, Malaysia, Mexico, New Zealand, Panama, Paraguay, Saudi Arabia, Taiwan, the United States, and Vietnam For use in Aruba, Austria, Azerbaijan, Bahrain, Belgium, Bermuda, Brazil, Bulgaria, 452063-002...
  • Page 31: Display Assembly Components

    Display assembly components Item Description Spare part number Display bezel 452307-001 Camera module (includes camera module brackets) 452304-001 Display Bracket Kit (includes left, top, and right brackets) 452303-001 Display panels 20.1-inch, WSXGA+, TFT, BrightView 452301-001 20.1-inch, WUXGA, TFT 452302-001 Speaker Kit (includes left and right speakers) 452310-001 Display inverter 452308-001...
  • Page 32: Plastics Kit

    Item Description Spare part number Display Rubber Pad Kit (not illustrated) 454595-001 Display Screw Kit (not illustrated) 452309-001 Plastics Kit Item Description Spare part number Plastics Kit 448171-001 WLAN module compartment cover (includes 1 captive screw, secured by a C-clip) ExpressCard slot bezel TV tuner module compartment cover (includes 1 captive screw, secured by a C-clip) Memory module compartment cover (includes 2 captive screws, secured by C-clips)
  • Page 33: Mass Storage Devices

    Mass storage devices Item Description Spare part number Optical drives (include bezel and bracket) DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 448157-001 HD-DVD Drive 448156-001 Hard drives (include hard drive bracket) 250-GB, 5400-rpm 454605-001 200-GB, 4200-rpm 448155-001 160-GB, 5400-rpm 448154-001 120-GB, 7200-rpm...
  • Page 34: Miscellaneous Parts

    Miscellaneous parts Description Spare part number 180-W PFC AC adapter 448160-001 ATSC/NTSC TV tuner antenna 439131-001 ATSC/NTSC/PAL TV tuner 439130-001 Bluetooth headset 443783-001 Composite video cable 407939-001 DVB-T tuner 412175-001 DVB-T antenna adapter 412176-001 ExpressCard Kit (includes software CD) 445170-001 Infrared emitter with cable 439129-001 Optical wired mouse...
  • Page 35: Sequential Part Number Listing

    Description Spare part number Phillips PM2.5×12.0 captive screw ● Phillips PM2.5×11.0 screw ● Phillips PM2.5×8.0 captive screw ● Phillips PM2.5×8.0 screw ● Phillips PM2.5×5.0 screw ● Phillips PM2.5×4.0 screw ● Phillips PM2.5×3.0 broad-head screw ● ● Black Phillips PM2.0×5.0 captive screw Silver Phillips PM2.0×5.0 captive screw ●...
  • Page 36 Spare part Description number 441086-002 Intel 802.11a/b/g/n WLAN module for use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia, Cyprus, the Czech Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan...
  • Page 37 Spare part Description number 448162-001 Processor fan 448163-001 Video board fan 448164-001 Subwoofer (includes rubber isolators) 448165-001 Remote control for use in North America 448165-002 Remote control for use in Europe, the Middle East, and Africa 448166-001 Fingerprint reader board (includes cable) 448167-001 TouchPad on/off board (includes cable) 448168-001...
  • Page 38 Spare part Description number 452309-001 Display Screw Kit 452310-001 Speaker Kit (includes left and right speakers) 452311-001 Hinge cover 452312-001 512-MB memory module (PC2-5300, 667-MHz, DDR2) 452313-001 100-GB, 7200-rpm hard drive (includes hard drive bracket) 452314-001 Front USB board (includes cable) 452315-001 Rear USB board (includes cable) 452316-001...
  • Page 39: Removal And Replacement Procedures

    Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: Magnetic screwdriver ● Phillips P0 and P1 screwdrivers ● Flat-bladed screwdriver ● Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.
  • Page 40: Cables And Connectors

    Cables and connectors CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.
  • Page 41: Grounding Guidelines

    Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.
  • Page 42: Packaging And Transporting Guidelines

    Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations. ●...
  • Page 43: Equipment Guidelines

    Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps ● with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.
  • Page 44: Unknown User Password

    Unknown user password If the computer you are servicing has an unknown user password, follow these steps to clear the password. NOTE: These steps also clear CMOS. Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 45: Component Replacement Procedures

    Component replacement procedures This chapter provides removal and replacement procedures. There are as many as 154 screws, in 18 different sizes, that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw size and location during removal and replacement.
  • Page 46: Battery

    Battery Description Spare part number 9-cell, 2.55-Ah, 83-Wh battery 448158-001 Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 47: Computer Feet

    Computer feet Description Spare part number Rubber Feet Kit (includes 11 computer feet in 4 sizes) 452320-001 The computer feet are adhesive-backed rubber pads. The feet attach to the base enclosure in the locations illustrated below. Component replacement procedures...
  • Page 48: Display Assembly Internal Components

    Display assembly internal components NOTE: If it has been determined that the display bezel, camera module, display inverter, display panel, or speakers are the components that must be replaced to complete the computer repair, the display assembly does not have to be completely removed from the computer. Replacement of these components can be completed by removing only the display bezel.
  • Page 49 Remove the following screw covers and logo labels: (1) Two rubber screw covers on the display bezel top edge corners (2) Two rubber screw covers on the display bezel top edge (3) Four rubber screw covers on the display bezel left and right sides (4) Speaker logo label on the display bezel lower left edge (5) Computer model logo label on the display bezel lower right edge Remove the ten Phillips PM2.5×5.0 screws that secure the display bezel to the display assembly.
  • Page 50 Remove the display bezel (3). The display bezel is available using spare part number 452307-001. If it is necessary to replace the camera module, remove the two Phillips PM2.5×5.0 screws (1) that secure the camera module to the display enclosure. Release the camera module (2) from the display enclosure as far as the camera module cable allows.
  • Page 51 Disconnect the two display panel cables (2) and the backlight cable (3) from the display inverter. Remove the display inverter. The display inverter is available using spare part number 452308-001. If it is necessary to replace the display panel, remove the eight Phillips PM2.5×5.0 screws that secure the display panel to the display enclosure.
  • Page 52 Squeeze the tabs on the display panel cable connector (2) together and disconnect the cable (3) from the display panel. Remove the display panel. The display panel is available using spare part numbers 452301-001 (20.1-inch, WSXGA+BrightView) and 452302-001 (20.1-inch, WUXGA). If it is necessary to replace the speakers, disconnect the speaker cable connectors (1) from the speaker extension cable connectors.
  • Page 53: Hard Drive

    Hard drive NOTE: All hard drive spare part kits include a hard drive bracket. Description Spare part number 250-GB, 5400-rpm 454605-001 200-GB, 4200-rpm 448155-001 160-GB, 5400-rpm 448154-001 120-GB, 7200-rpm 448152-001 120-GB, 5400-rpm 448153-001 100-GB, 7200-rpm 452313-001 Before removing the hard drive, follow these steps: Shut down the computer.
  • Page 54 Remove the hard drives (3) from the hard drive compartments. If it is necessary to replace the hard drive bracket, remove the four Phillips PM3.0×4.0 screws (1) that secure the hard drive bracket to the hard drive. Lift the bracket (2) straight up to remove it from the hard drive. Reverse this procedure to reassemble and install the hard drive.
  • Page 55: Wlan Module

    WLAN module Description Spare part number Intel 802.11a/b/g/n WLAN modules: ● For use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei, 441086-001 Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States, Venezuela, and Vietnam ●...
  • Page 56 Lift the right side of the WLAN module compartment cover (2), swing the cover up and to the left, and remove the cover. The WLAN module compartment cover is included in the Plastics Kit, spare part number 448171-001. Disconnect the WLAN antenna cables (1) from the WLAN module. NOTE: The main WLAN antenna cable (labeled with the number 1 or with a black band) is connected to the WLAN module “Main”...
  • Page 57: Tv Tuner Module

    TV tuner module Description Spare part number For use only in Europe, the Middle East, and Africa 448168-002 For use only in North America 448168-001 Before removing the TV tuner module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 58: Memory Module

    Remove the TV tuner module (3) by pulling it away from the slot at an angle. NOTE: The TV tuner module is designed with a notch (4) to prevent incorrect installation into the TV tuner module slot. Reverse this procedure to install the TV tuner module. Memory module Description Spare part number...
  • Page 59 Lift the rear edge of the cover (2), swing it forward, and remove the cover. The memory module compartment cover is included in the Plastics Kit, spare part number 448171-001. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module. (The edge of the module opposite the slot rises away from the computer.) Remove the module (2) by pulling it away from the slot at an angle.
  • Page 60: Optical Drive

    Optical drive NOTE: All optical drive spare part kits include an optical drive bezel and bracket. Description Spare part number HD-DVD 448156-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 448157-001 Before removing the optical drive, follow these steps: Shut down the computer.
  • Page 61 Remove the optical drive bracket (2). Reverse the above procedure to reassemble and install the optical drive. Component replacement procedures...
  • Page 62: Keyboard

    Keyboard Description For use in: Spare part number For use in: Spare part number Denmark, Finland, Norway, and 448159-DH1 Latin America 448159-161 Sweden France 448159-051 South Korea 448159-AD1 French Canada 448159-121 Spain 448159-071 Germany 448159-041 The United Kingdom 448159-031 The Netherlands and Europe 448159-B31 The United States 448159-001...
  • Page 63 Open the computer as far as possible. Lift the front edge of the keyboard (1) until it rests at an angle. Slide the keyboard (2) forward until the tabs on the rear edge of the keyboard disengage from the slots in the top cover. Rotate the rear edge of the keyboard (3) forward until it rests upside down on the palm rest.
  • Page 64: Hinge Cover

    Hinge cover Description Spare part number Hinge cover 452311-001 Before removing the hinge cover, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 65: Rear Cover

    Rear cover Description Spare part number Rear cover 448161-001 Before removing the rear cover, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 66 Remove the four Phillips PM2.5×4.0 broad-head screws (2) that secure the rear cover to the computer. Turn the computer right-side up, with the front toward you. Open the computer as far as possible. Remove the rear cover. Reverse this procedure to install the rear cover. Chapter 4 Removal and replacement procedures...
  • Page 67: Top Cover

    Top cover Description Spare part number Top cover (includes TouchPad board cable and TouchPad button cable, and LED boards and cables) 448174-001 Before removing the top cover, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 68 Remove the four Phillips PM2.5×5.0 screws (1) and the two Phillips PM2.5×11.0 screws (2) that secure the top cover to the computer. Turn the computer right-side up, with the front toward you. Open the computer as far as possible. Disconnect the following cables: (1) Fingerprint reader board cable (2) LED board cable (3) TouchPad board cable...
  • Page 69: Fingerprint Reader Board

    Lift the rear edge of the top cover (2) until the top cover disengages from the computer. Remove the top cover. Reverse this procedure to install the top cover. Fingerprint reader board Description Spare part number Fingerprint reader board (includes cable) 448166-001 Before removing the fingerprint reader board, follow these steps: Shut down the computer.
  • Page 70: Touchpad On/Off Board

    Remove the fingerprint reader board: Turn the top cover upside down, with the front toward you. Remove the two silver Phillips PM2.0×4.0 screws (1) that secure the fingerprint reader board and bracket to the top cover. Remove the fingerprint reader board bracket (2) and fingerprint reader board (3). Reverse this procedure to install the fingerprint reader board.
  • Page 71 Rear cover (see Rear cover on page Top cover (see Top cover on page Remove the TouchPad on/off board: Turn the top cover upside down, with the front toward you. Remove the two silver Phillips PM2.0×4.0 screws (1) that secure the TouchPad on/off board to the top cover.
  • Page 72: Display Assembly

    Display assembly Description Spare part number 20.1-inch, WSXGA BrightView display assembly (includes camera module and cable, microphones, 452299-001 speakers, and WLAN antennae) 20.1-inch, WUXGA BrightView display assembly (includes camera module and cable, microphones, 452300-001 speakers, and WLAN antennae) Before removing the display assembly, follow these steps: Shut down the computer.
  • Page 73 Remove the six Phillips PM3.0×8.0 screws that secure the display assembly to the computer. Turn the computer display-side up, with the front toward you. Open the computer to an upright position. Disconnect the following cable connectors: (1) Display panel cable (2) Camera module cable (3) Speaker cable (4) Microphone cable...
  • Page 74 Remove the WLAN antenna cables (5) from the opening in the system board. CAUTION: The display assembly will be unsupported when the following screws are removed. To prevent damage to the display assembly, support the display assembly before removing the screws. Remove the six Phillips PM3.0×8.0 screws (1) that secure the display assembly to the computer.
  • Page 75: Audio/Infrared Board

    Audio/infrared board Description Spare part number Audio/infrared board 452316-001 Before removing the audio/infrared board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 76: Bluetooth Module

    Reverse this procedure to install the audio/infrared board. Bluetooth module NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is available in the Cable Kit, spare part number 448169-001. Description Spare part number Bluetooth module 398393-002 Before removing the Bluetooth module, follow these steps:...
  • Page 77: Front Usb Board

    Remove the Bluetooth module (3) from the base enclosure. Reverse this procedure to install the Bluetooth module. Front USB board Description Spare part number Front USB board 452314-001 Before removing the front USB board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 78: Power Connector Led Board

    Remove the front USB board: Disconnect the front USB board cable (1) from the system board. Remove the two Phillips PM2.5×4.0 screws (2) that secure front USB board the to the computer. Remove the front USB board (3). Reverse this procedure to install the front USB board. Power connector LED board Description Spare part number...
  • Page 79: Rear Usb Board

    Rear cover (see Rear cover on page Top cover (see Top cover on page Remove the power connector LED board: Disconnect the power connector LED board (1) from the system board. Remove the power connector LED board (2). Reverse this procedure to install the power connector LED board. Rear USB board Description Spare part number...
  • Page 80: Subwoofer

    Rear cover (see Rear cover on page Top cover (see Top cover on page Remove the rear USB board: Disconnect the rear USB board cable (1) from the system board. Remove the Phillips PM2.5×4.0 screw (2) that secures rear USB board the to the computer. Remove the rear USB board (3).
  • Page 81: Video Connector Board

    Hinge cover (see Hinge cover on page Rear cover (see Rear cover on page Top cover (see Top cover on page Remove the subwoofer: Disconnect the subwoofer cable (1) from the system board. Remove the three Phillips PM2.5×8.0 screws (2) that secure subwoofer the to the base enclosure. Remove the subwoofer (3).
  • Page 82 Remove the battery (see Battery on page 38). Remove the following components: Hard drive (see Hard drive on page Optical drive (see Optical drive on page Keyboard (see Keyboard on page Hinge cover (see Hinge cover on page Rear cover (see Rear cover on page Top cover (see Top cover on page...
  • Page 83: Processor Fan

    Processor fan Description Spare part number Processor fan 448162-001 NOTE: To properly ventilate the computer, allow at least a 7.6-cm (3-inch) clearance on the left and right sides and rear panel of the computer. The computer uses two electric fans for ventilation. The fans are controlled by a temperature sensor and are designed to turn on automatically when high temperature conditions exist.
  • Page 84: System Board

    Remove the processor fan (3). Reverse this procedure to install the processor fan. System board Description Spare part number System board (includes power connector cable, ExpressCard assembly, and replacement thermal 448145-001 material) Before removing the system board, follow these steps: Shut down the computer.
  • Page 85 When replacing the system board, be sure that the following components are removed from the defective system board and installed on the replacement system board: Memory module (see Memory module on page ● RTC battery (see RTC battery on page ●...
  • Page 86 Disconnect the following cable connectors from the system board: (1) Speaker cable (2) Microphone cable (3) Audio/infrared board cable (4) Subwoofer cable (5) Audio connector board cable Disconnect the following cables from the system board: (1) Bluetooth module cable (2) Front USB board cable (3) Processor fan cable (4) Composite video connector board cable Remove the two SM1.5×9.0 screws (1) on each side of the expansion port 3 connector.
  • Page 87 Remove the four Phillips PM2.5×4.0 screws (2) that secure the system board to the base enclosure. Loosen the captive Phillips PM2.5×14.0 screw (3) that secures the video heat sink and system board to the base enclosure. Use the optical drive connector (1) to lift the right side of the system board (2) until it rests at an angle.
  • Page 88: Audio Connector Board

    Audio connector board Description Spare part number Audio connector board (includes cable) 452317-001 Before removing the audio connector board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 89: Rtc Battery

    Remove the audio connector board (3) from the base enclosure. Reverse this procedure to install the audio connector board. RTC battery NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all passwords and CMOS settings to be cleared. Description Spare part number RTC battery...
  • Page 90 Subwoofer (see Subwoofer on page System board (see System board on page Remove the RTC battery: Remove the RTC battery from the socket on the system board. ▲ Reverse this procedure to install the RTC battery. Chapter 4 Removal and replacement procedures...
  • Page 91: Processor Heat Sink

    Processor heat sink Description Spare part number Processor heat sink (includes replacement thermal material) 448175-001 Before removing the processor heat sink, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 92 Remove the processor heat sink (3). NOTE: Due to the adhesive quality of the thermal material located between the processor heat sink and system board components, it may be necessary to move the processor heat sink from side to side to detach it. NOTE: The thermal material must be thoroughly cleaned from the surfaces of the processor heat sink (1) and the system board (2) each time the processor heat sink is removed.
  • Page 93: Processor

    Processor NOTE: All processor spare part kits include replacement thermal material. Desription Spare part number Intel Core 2 Extreme processors (4-MB L2 cache, 800-MHz FSB, 44-W): X7900 2.8-GHz processor 453908-001 X7800 2.6-GHz processor 455738-001 and 452327-001 Intel Core 2 Duo processors (4-MB L2 cache, 800-MHz FSB, 35-W): T7700 2.4-GHz processor 448148-001 T7500 2.2-GHz processor...
  • Page 94 Lift the processor (2) straight up and remove it. NOTE: The gold triangle (3) on the processor must be aligned with the triangle icon (4) embossed on the processor slot when you install the processor. Reverse this procedure to install the processor. Chapter 4 Removal and replacement procedures...
  • Page 95: Video Board Heat Sink

    Video board heat sink Description Spare part number Video board heat sink (includes replacement thermal material) 448176-001 Before removing the video board heat sink, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 96 Remove the video board heat sink (4). NOTE: Due to the adhesive quality of the thermal material located between the video board heat sink and system board components, it may be necessary to move the video board heat sink from side to side to detach it.
  • Page 97: Video Board Fan

    Video board fan Description Spare part number Video board fan 448163-001 NOTE: To properly ventilate the computer, allow at least a 7.6-cm (3-inch) clearance on the left and right sides and rear panel of the computer. The computer uses two electric fans for ventilation. The fans are controlled by a temperature sensor and are designed to turn on automatically when high temperature conditions exist.
  • Page 98: Video Board

    Remove the video board fan (2). Reverse this procedure to install the video board fan. Video board Description Spare part number nVidia video board (includes replacement thermal material) 454311-001 Before removing the video board fan, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 99 System board (see System board on page Video board heat sink (see Video board heat sink on page Remove the video board: Remove the two Phillips PM2.5×4.0 screws (1) that secure the video board to the system board. Lift the right side of the video board (2) until it rests at an angle. Remove the video board (3) by pulling it away from the video board slot at an angle.
  • Page 100: Computer Setup

    Computer Setup Starting Computer Setup Computer Setup is a ROM-based information and customization utility that can be used even when the Windows operating system is not working or will not load. NOTE: The fingerprint reader does not work when accessing Computer Setup. The utility reports information about the computer and provides settings for startup, security, and other preferences.
  • Page 101: Using Computer Setup

    Using Computer Setup Changing the language of Computer Setup The following procedure explains how to change the language of Computer Setup. If Computer Setup is not already running, begin at step 1. To start Computer Setup, turn on or restart the computer, and then press while “F10 = ROM Based Setup”...
  • Page 102: Restoring Default Settings In Computer Setup

    Restoring default settings in Computer Setup The following procedure explains how to restore Computer Setup default settings. If Computer Setup is not already running, begin at step 1. If Computer Setup is already running, begin at step 2. To start Computer Setup, turn on or restart the computer, and then press while “F10 = ROM Based Setup”...
  • Page 103: Computer Setup Menus

    Computer Setup menus The menu tables in this section provide an overview of Computer Setup options. NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select To do this System information View identification information about the computer.
  • Page 104: Security Menu

    Security menu Select To do this Setup password Enter, change, or delete a setup password. Power-On password Enter, change, or delete a power-on password. Diagnostics menu Select To do this Hard Drive Self-Test options Run a comprehensive self-test on any hard drive in the system. Memory Check Run a comprehensive check on system memory.
  • Page 105: System Configuration Menu

    System Configuration menu NOTE: Some of the listed System Configuration options may not be supported by your computer. Select To do this Language (or press f2) Change the Computer Setup language. Boot options ● Set f9, f10, and delay when starting up. Enable/disable CD-ROM boot.
  • Page 106: Specifications

    Specifications Computer specifications Metric U.S. Dimensions Width 47.5 cm 18.70 in Depth 33.9 cm 13.35 in Height 5.9 cm 2.32 in Weight (with optical drive, hard drive, 7.00 kg 15.44 lbs and battery) Second hard drive adds: 0.13 kg 0.28 lbs Camera adds: 0.009 kg 0.02 lbs...
  • Page 107: 20.1-Inch, Wuxga Display Specifications

    Metric U.S. Operating 0.75 g zero-to-peak, 10 Hz to 500 Hz, 0.25 oct/min sweep rate Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures.
  • Page 108: Inch Wsxga+ Display Specifications

    20.1-inch WSXGA+ display specifications Metric U.S. Dimensions Height 27.40 cm 10.79 in Width 43.55 cm 17.15 in Diagonal 51.10 cm 20.11 in Number of colors Up to 16.8 million Contrast ratio 200:1 Brightness 180 nits typical Pitch resolution Pitch 0.172 × 0.172 mm Format 1680 ×...
  • Page 109: Hard Drive Specifications

    Hard drive specifications 250-GB* 200-GB* 160-GB* 120-GB* 100-GB* Dimensions Height 9.5 mm 9.5 mm 9.5 mm 9.5 mm 9.5 mm Width 70 mm 70 mm 70 mm 70 mm 70 mm Weight 101 g 101 g 101 g 101 g 101 g Interface type ATA-7...
  • Page 110: Dvd±Rw And Cd-Rw Super Multi Double-Layer Combo Drive Specifications

    DVD±RW and CD-RW Super Multi Double-Layer Combo Drive specifications Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-R and CD-RW CD-ROM, CD-ROM XA, MIXED MODE DVD+R, DVD+RW, DVD-R, DVD-RW, CD, CD-I, CD-I Bridge (Photo-CD, Video DVD-RAM CD), Multisession CD (Photo-CD, CD- EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,...
  • Page 111: System Dma Specifications

    System DMA specifications Hardware DMA System function DMA0 Not applicable DMA1* Not applicable DMA2* Not applicable DMA3 Not applicable DMA4 Direct memory access controller DMA5* Available for PC Card DMA6 Not assigned DMA7 Not assigned *PC Card controller can use DMA 1, 2, or 5. System DMA specifications 103...
  • Page 112: System Interrupt Specifications

    System interrupt specifications Hardware IRQ System function IRQ0 System timer IRQ1 Standard 101-/102-Key or Microsoft® Natural Keyboard IRQ2 Cascaded IRQ3 Intel 82801DB/DBM USB2 Enhanced Host Controller—24CD IRQ4 COM1 IRQ5* Conexant AC—Link Audio Intel 82801DB/DBM SMBus Controller— 24C3 Data Fax Modem with SmartCP IRQ6 Diskette drive IRQ7*...
  • Page 113: System I/O Address Specifications

    System I/O address specifications I/O address (hex) System function (shipping configuration) 000 - 00F DMA controller no. 1 010 - 01F Unused 020 - 021 Interrupt controller no. 1 022 - 024 Opti chipset configuration registers 025 - 03F Unused 02E - 02F 87334 “Super I/O”...
  • Page 114 I/O address (hex) System function (shipping configuration) 220 - 22F Entertainment audio 230 - 26D Unused 26E - 26 Unused 278 - 27F Unused 280 - 2AB Unused 2A0 - 2A7 Unused 2A8 - 2E7 Unused 2E8 - 2EF Reserved serial port 2F0 - 2F7 Unused 2F8 - 2FF...
  • Page 115: System Memory Map Specifications

    System memory map specifications Size Memory address System function 640 KB 00000000-0009FFFF Base memory 128 KB 000A0000-000BFFFF Video memory 48 KB 000C0000-000CBFFF Video BIOS 160 KB 000C8000-000E7FFF Unused 64 KB 000E8000-000FFFFF System BIOS 15 MB 00100000-00FFFFFF Extended memory 58 MB 04800000-07FFFFFF Super extended memory 58 MB...
  • Page 116: Screw Listing

    Screw listing This section provides specification and reference information for the screws and screw locks used in the computer. All screws and screw locks listed in this section are available in the Screw Kit, spare part number 448172-001, and the Display Screw Kit, spare part number 452309-001. Phillips PM2.5×5.0 screw Color Quantity...
  • Page 117 Where used: 10 screws that secure the display bezel to the display assembly Where used: (1) Two screws that secure the camera module to the display enclosure (2) Eight screws that secure the display panel to the display enclosure Phillips PM2.5×5.0 screw 109...
  • Page 118 Where used: 4 screws that secure the speakers to the display enclosure Where used: (1) Two screws that secure the WLAN module to the system board (2) One screw that secures the rear cover to the computer (3) Two screws that secure the top cover to the computer 110 Chapter 7 Screw listing...
  • Page 119 Where used: 2 screws that secure the TV tuner module to the system board Where used: (1) Four screws that secure the keyboard to the computer (2) Four screws that secure the top cover to the computer Phillips PM2.5×5.0 screw 111...
  • Page 120 Where used: 2 screws that secure the top cover to the computer Where used: (1) Two screws that secure the audio/infrared board to the base enclosure (2) One screw that secures the rear USB board to the base enclosure (3) Two screws that secure the front USB board to the base enclosure (4) One screw that secures the video connector board to the base enclosure 112 Chapter 7 Screw listing...
  • Page 121: Black Phillips Pm2.0×5.0 Captive Screw

    Black Phillips PM2.0×5.0 captive screw Color Quantity Length Thread Head diameter Black 5.0 mm 2.0 mm 4.5 mm Where used: (1) Six captive screws (secured by C-clips) that secure the hard drive bay cover to the computer (2) One captive screw (secured by a C-clip) that secure the WLAN module compartment cover to the computer (3) Two captive screws (secured by C-clips) that secure the memory module compartment cover to the computer...
  • Page 122: Phillips Pm2.5×12.0 Captive Screw

    Phillips PM2.5×12.0 captive screw Color Quantity Length Thread Head diameter Silver 12.0 mm 2.5 mm 5.0 mm Where used: 2 captive screws (secured by C-clips) that secure the hard drives to the computer 114 Chapter 7 Screw listing...
  • Page 123: Phillips Pm3.0×4.0 Screw

    Phillips PM3.0×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 3.0 mm 5.0 mm Where used: 8 screws that secure the hard drive brackets to the two hard drives Phillips PM3.0×4.0 screw 115...
  • Page 124: Phillips Pm2.5×8.0 Screw

    Phillips PM2.5×8.0 screw Color Quantity Length Thread Head diameter Black 8.0 mm 2.5 mm 5.0 mm Where used: (1) One screw that secures the optical drive to the computer (2) Three screws that secure the keyboard to the computer (3) Seven screws that secure the rear cover to the computer 116 Chapter 7 Screw listing...
  • Page 125 Where used: 10 screws that secure the top cover to the computer Where used: 3 screws that secure the subwoofer to the base enclosure Where used: 2 screws that secure the processor fan to the base enclosure Phillips PM2.5×8.0 screw 117...
  • Page 126: Phillips Pm2.0×3.0 Screw

    Phillips PM2.0×3.0 screw Color Quantity Length Thread Head diameter Silver 3.0 mm 2.0 mm 4.5 mm Where used: 2 screws that secure the optical drive bracket to the optical drive 118 Chapter 7 Screw listing...
  • Page 127: Phillips Pm3.0×8.0 Screw

    Phillips PM3.0×8.0 screw Color Quantity Length Thread Head diameter Black 8.0 mm 3.0 mm 5.0 mm Where used: 4 screws that secure the hinge cover to the computer Where used: 6 screws that secure the display assembly to the computer Phillips PM3.0×8.0 screw 119...
  • Page 128 Where used: 6 screws that secure the display assembly to the computer 120 Chapter 7 Screw listing...
  • Page 129: Phillips Pm2.5×4.0 Screw

    Phillips PM2.5×4.0 screw Color Quantity Length Thread Head diameter Black 4.0 mm 2.5 mm 5.0 mm Where used: (1) Four screws that secure the system board to the base enclosure (2) Two screws that secure the audio connector board to the base enclosure Phillips PM2.5×4.0 screw 121...
  • Page 130: Phillips Pm3.0×12.0 Screw

    Where used: 2 screws that secure the video board to the system board Phillips PM3.0×12.0 screw Color Quantity Length Thread Head diameter Black 12.0 mm 3.0 mm 5.0 mm Where used: 4 screws that secure the rear cover to the computer 122 Chapter 7 Screw listing...
  • Page 131: Phillips 2.5×3.0 Broad-Head Screw

    Phillips 2.5×3.0 broad-head screw Color Quantity Length Thread Head diameter Black 3.0 mm 2.5 mm 7.0 mm Where used: 4 screws that secure the rear cover to the computer Phillips 2.5×3.0 broad-head screw 123...
  • Page 132: Phillips Pm2.5×11.0 Screw

    Phillips PM2.5×11.0 screw Color Quantity Length Thread Head diameter Black 11.0 mm 2.5 mm 5.0 mm Where used: 2 screws that secure the top cover to the computer 124 Chapter 7 Screw listing...
  • Page 133: Silver Phillips Pm2.0×4.0 Screw

    Silver Phillips PM2.0×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 2.0 mm 4.5 mm Where used: (1) Two screws that secure the fingerprint reader board to the top cover (2) Two screws that secure the TouchPad on/off board to the top cover Silver Phillips PM2.0×4.0 screw 125...
  • Page 134 Where used: 2 screws that secure the Bluetooth module to the base enclosure 126 Chapter 7 Screw listing...
  • Page 135: Slotted Sm1.5×9.0 Shoulder Screw

    Slotted SM1.5×9.0 shoulder screw Color Quantity Length Thread Head diameter Silver 9.0 mm 1.5 mm 1.5 mm Where used: 2 screws that secure the system board to the base enclosure Slotted SM1.5×9.0 shoulder screw 127...
  • Page 136: Phillips Pm2.5×13.0 Captive Screw

    Phillips PM2.5×13.0 captive screw Color Quantity Length Thread Head diameter Silver 13.0 mm 2.5 mm 5.0 mm Where used: One captive screw (secured inside the video heat sink) that secures the system board and video board heat sink to the base enlcosure 128 Chapter 7 Screw listing...
  • Page 137: Silver Phillips Pm2.0×5.0 Captive Screw

    Silver Phillips PM2.0×5.0 captive screw Color Quantity Length Thread Head diameter Silver 5.0 mm 2.0 mm 4.5 mm Where used: (1) Three captive screws (secured by C-clips) that secure the processor heat sink to the system board (2) Four captive screws (secured by C-clips) that secure the video board heat sink to the system board Silver Phillips PM2.0×5.0 captive screw 129...
  • Page 138: Phillips Pm2.5×8.0 Captive Screw

    Phillips PM2.5×8.0 captive screw Color Quantity Length Thread Head diameter Silver 8.0 mm 2.5 mm 5.0 mm Where used: 2 captive screws (secured inside the video board heat sink) that secure the video board heat sink to the system board 130 Chapter 7 Screw listing...
  • Page 139: Black Phillips Pm2.0×4.0 Screw

    Black Phillips PM2.0×4.0 screw Color Quantity Length Thread Head diameter Black 4.0 mm 2.0 mm 4.5 mm Where used: 3 screws that secure the video board fan to the video board heat sink Black Phillips PM2.0×4.0 screw 131...
  • Page 140: Backup And Recovery

    Backup and Recovery Recovering system information Tools provided by the operating system and Recovery Manager software are designed to help you with the following tasks for safeguarding your information and restoring it in case of a system failure: Backing up your information regularly to protect your important system files. ●...
  • Page 141: Backing Up Your Information

    Number each disc before inserting it into the computer optical drive. ● If necessary, you can exit the program before you have finished creating the recovery discs. The next ● time you open Recovery Manager, you will be prompted to continue the disc creation process. To create a set of recovery discs: Select Start >...
  • Page 142: Back Up Suggestions

    Back up suggestions Create a set of recovery discs using Recovery Manager. ● ● Create system restore points using the Windows System Restore feature, and periodically copy them to disc. Store personal files in the Documents folder and back up these folders periodically. ●...
  • Page 143 The System Protection window opens. Follow the on-screen instructions. Recovering system information 135...
  • Page 144: Restore To A Previous Date And Time

    Restore to a previous date and time To revert to a restore point (created at a previous date and time), when the computer was functioning optimally, follow these steps: Select Start > Control Panel > System and Maintenance > System. In the left pane, click System protection.
  • Page 145: Performing A Recovery

    Performing a recovery Recovery Manager software allows you to repair or restore the system if you experience system failure or instability. Recovery Manager works from recovery discs that you create or from a dedicated recovery partition on the hard drive. NOTE: Windows has its own built-in repair features, such as System Restore and driver roll-back capabilities.
  • Page 146: Connector Pin Assignments

    Connector pin assignments Audio-out (headphone) Signal Audio out, left channel Audio out, right channel Ground Audio-in (microphone) Signal Audio signal in Audio signal in Ground 138 Chapter 9 Connector pin assignments...
  • Page 147: External Monitor

    External monitor Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock External monitor 139...
  • Page 148: Network)

    RJ-45 (network) Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused 140 Chapter 9 Connector pin assignments...
  • Page 149: Universal Serial Bus

    Universal Serial Bus Signal +5 VDC Data - Data + Ground Universal Serial Bus 141...
  • Page 150: 10 Power Cord Set Requirements

    10 Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.
  • Page 151: Requirements For Specific Countries Or Regions

    Requirements for specific countries or regions Country or region Accredited agency Applicable note number Australia EANSW Austria Belgium CEBC Canada Denmark DEMKO Finland FIMKO France Germany Italy Japan METI South Korea The Netherlands KEMA Norway NEMKO The People's Republic of China Sweden SEMKO Switzerland...
  • Page 152: 11 Recycling

    11 Recycling Battery When a battery has reached the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for computer battery disposal. Display WARNING! The backlight contains mercury. Caution must be exercised when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury.
  • Page 153 Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.
  • Page 154 Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside down. Remove all screws that secure the display panel frame to the display panel.
  • Page 155 Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.
  • Page 156 Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside down. Remove the backlight frame from the display panel. WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury. 148 Chapter 11 Recycling...
  • Page 157 Remove the backlight from the backlight frame. Disconnect the display cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.
  • Page 158: Index

    Index Symbols/Numerics boot order 97 components 1394 port 16 bottom components 17 bottom 17 button components 7, 9 buttons 7, 9 buttons display 6 AC adapter, spare part DVD 8 fingerprint reader 9 number 26, 28 media 7 front 12 analog channel output jack 14 next/fast forward 8 keys 11...
  • Page 159 Digital Media Slot light 16 DVD±RW and CD-RW Combo Drive diskette drive precautions 32 hard drive precautions 32 removal 52 precautions 32 product description 2 spare part number 22, 25, product description 1 display assembly 28, 52 removal 45 removal 64 specifications 102 spare part numbers 22, 25, spare part numbers 20, 29,...
  • Page 160 analog channel output volume mute 9 jack 14 wireless 9 packing guidelines 34 audio-in 12 password clearing 36 audio-out 12 passwords 96 mass storage devices, spare part headphone 12 pin assignments numbers 25 IR emitter 13 audio-in 138 media button 7 microphone 12 audio-out 138 memory check 96...
  • Page 161 removal 85 recovery, system 132, 137 display 99, 100 spare part numbers 21, 28, remote control DVD±RW and CD-RW Combo 30, 85 product description 4 Drive 102 processor fan spare part numbers 26, 29 hard drive 101 removal 75 remote control button 8 I/O addresses 105 spare part number 21, 29, removal/replacement...
  • Page 162 TouchPad on/off board video board heat sink removal 62 removal 87 spare part number 20, 29, spare part number 21, 29, transporting guidelines 34 video connector board treble light 10 removal 73 treble or bass volume down spare part number 20, 30, light 9 treble or bass volume scroll volume down light 9...
