Before removing the TouchPad on/off board, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the following components:
5.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover (see
e.
Top cover (see
f.
Remove the TouchPad on/off board:
Turn the top cover upside down, with the front toward you.
1.
Remove the two silver Phillips PM2.0×4.0 screws (1) that secure the TouchPad on/off board to the
2.
top cover.
Remove the TouchPad on/off board (2).
3.
Reverse this procedure to install the TouchPad on/off board.
Battery on page
36).
Hard drive on page
42)
Optical drive on page
Keyboard on page
50)
Hinge cover on page
Rear cover on page
53)
Top cover on page
55)
49)
52)
Component replacement procedures
59
