Spare part
number
448160-001
448161-001
448162-001
448163-001
448164-001
448165-001
448165-002
448166-001
448167-001
448168-001
448168-002
448168-003
448169-001
448171-001
448172-001
448173-001
448174-001
448175-001
448176-001
449137-001
455916-001
452063-001
452063-002
452063-003
452299-001
452300-001
452301-001
452302-001
28
Chapter 3 Illustrated parts catalog
Description
180-W AC adapter
Rear cover
Processor fan
Video board fan
Subwoofer (includes rubber isolators)
Remote control for use in North America
Remote control for use in Europe, the Middle East, and Africa
Fingerprint reader board (includes cable)
TouchPad on/off board (includes cable)
TV tuner module for use in North America
TV tuner module for use in Europe, the Middle East, and Africa
TV tuner module, NTSC/ATSC-compliant
Cable Kit
Plastics Kit (see
Plastics Kit on page 23
Screw Kit
Base enclosure (includes microphone and speaker extension cables and rubber feet)
Top cover (includes TouchPad board cable and TouchPad button cable, and LED boards and cables)
Processor heat sink (includes replacement thermal material)
Video board heat sink (includes replacement thermal material)
RTC battery
Wireless laser mouse
Intel 802.11a/b/g WLAN module for use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados,
Bermuda, Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador,
El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama,
Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States, Venezuela, and Vietnam
Intel 802.11a/b/g WLAN module for use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia,
Cyprus, the Czech Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary,
Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the
Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and
Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey,
Ukraine, the United Kingdom, and Uzbekistan
Intel 802.11a/b/g WLAN module for use in Australia, New Zealand, Pakistan, the People's Republic of China,
and South Korea
20.1-inch, WSXGA BrightView display assembly (includes camera module and cable, microphones, speakers,
and WLAN antennae)
20.1-inch, WUXGA BrightView display assembly (includes camera module and cable, microphones, speakers,
and WLAN antennae)
20.1-inch, WSXGA BrightView display panel
20.1-inch, WUXGA BrightView display panel
for more Plastics Kit information)
