Description
For use in:
French Canada
Germany
The Netherlands and Europe
Italy
Latin America
Saudi Arabia
Before removing the keyboard, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the hard drives (see
5.
Remove the keyboard:
Position the computer with the front toward you.
1.
Remove the three Phillips PM2.5×8.0 screws (1) and the four Phillips PM2.5×5.0 screws (2) that
2.
secure the keyboard to the computer.
Turn the computer display-side up, with the front toward you.
3.
Open the computer as far as possible.
4.
Lift the front edge of the keyboard (1) until it rests at an angle.
5.
Spare part number
448159-121
448159-041
448159-B31
448159-061
448159-161
448159-171
Battery on page 36).
Hard drive on page
For use in:
Taiwan
Thailand
Turkey
The United Kingdom
The United States
42).
Component replacement procedures
Spare part number
448159-AB1
448159-281
448159-141
448159-031
448159-001
