Display assembly

Description
20.1-inch, WSXGA BrightView display assembly (includes camera module and cable, microphones,
speakers, and WLAN antennae)
20.1-inch, WUXGA BrightView display assembly (includes camera module and cable, microphones,
speakers, and WLAN antennae)
Before removing the display assembly, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Disconnect the WLAN module antenna cables from the WLAN module (see
5.
on page
Remove the following components:
6.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover (see
e.
Top cover (see
f.
Remove the display assembly:
Close the computer and turn it upside down, with the front toward you.
1.
60
Chapter 4 Removal and replacement procedures
Battery on page
44).
Hard drive on page
Optical drive on page
Keyboard on page
Hinge cover on page
Rear cover on page
Top cover on page
36).
42)
49)
50)
52)
53)
55)
Spare part number
452299-001
452300-001
WLAN module
