4
Section
FUNCTIONAL SUMMARY
DARF64
See "APPENDIX F: PT-VME151A Differences From VME131/141" on page 91 for in-depth discussion
of initialization issues. See APPENDIX G: and APPENDIX H: for more information.
70 Extensible Single Board Computer/Controller User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 7: DARF64 Registers
ADDRESS
NAME
18000000h
DMALAR
18000004h
DMAVAR
18000008h
DMATC
1800000Ch
DCSR
18000010h
VMEBAR
18000014h
RXDATA
18000018h
RXADDR
1800001Ch
RXCTL
18000020h
BUSSEL
18000024h
IVECT
18000028h
APBR
1800002Ch
TXDATA
18000030h
TXADDR
18000034h
TXCTRL
18000038h
LMFIFO
1800003Ch
MODE
18000040h
SA64BAR
18000044h
MA64MAR
18000048h
LAG
1800004ch
DMAVTC
FUNCTION
DMA Local Address Register
DMA VMEbus Address Register
DMA Transfer Count
Control and Status Register
VMEbus Slave Base Address Register
Receive FIFO Data bits output latch
Receive FIFO Address bits output latch
Receive FIFO Control bits output latch
VMEbus Select
VMEbus Interrupt Vector
Access Protect Boundary
Transmit FIFO Data bits output latch
Transmit FIFO Address bits output latch
Transmit FIFO Control bits output latch
Location Monitor FIFO read port
Mode Control
Slave A64 Base Address Register
Master A64 Base Address Register
Local Address Generator
DMA VMEbus Transfer Count
INIT
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
