Register Maps

The "INIT" column in the register map descriptions below identify the initial register values typically
programmed by PTI for our applications. All "INIT" values are in hexadecimal, registers that are "don't
care" at initialization time contain a hyphen.

ACC

See "APPENDIX F: PT-VME151A Differences From VME131/141" on page 91 for in-depth discus-
sion of initialization issues. See APPENDIX G: and APPENDIX H: for more information.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table 6: ACC Register Map

ADDRESS REGISTER
10000000h STAT0
10000001h STAT1
10000002h GENCTL
10000003h VINT
10000004h VREQ
10000005h VARB
10000006h ID
10000007h CTL2
10000008h 7IS
10000009h LIS
1000000Ah 7IE
1000000Bh LIE
1000000Ch VIE
1000000Dh IC10
1000000Eh IC32
1000000Fh IC54
Extensible Single Board Computer/Controller User's Manual 69
FUNCTION
Status Register 0
Status Register 1
General Control Register
VMEbus Interrupter Register
VMEbus Requester Register
VMEbus Arbiter Register
ID Register
Control Register 2
Level 7 Interrupt Status Register
Local Interrupt Register
Level 7 Interrupt Enable Register
Local Interrupt Enable Register
VMEbus Interrupt Enable Register
Local Interrupts 1 and 0 Control
Local Interrupts 3 and 2 Control
Local Interrupts 5 and 4 Control
Performance Computer
INIT
-
-
1C
-
03
00
-
00
-
-
-
00
-
13
45
62
