CONNECTOR PINOUTS
The DRAM mounting standoffs are used to carry power and ground to the DRAM module.
80 Extensible Single Board Computer/Controller User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 17: DRAM Module Connections
Pin
Signal
23
GND
24
A3
25
A4
26
A5
27
GND
28
RAS2
29
PTST
30
WE2
31
GND
32
D16
33
D17
34
D18
35
D19
36
D20
37
D21
38
D22
39
D23
40
GND
Table 18: EPAK mounting standoffs
Mounting pin
1
2
3
Pin
Signal
63
OE
64
A9
65
A10
66
A11
67
GND
68
RAS3
69
RASP
70
WE3
71
GND
72
D24
73
D25
74
D26
75
D27
76
D28
77
D29
78
D30
79
D31
80
GND
Signal
+5V
+5V
GND
