CONNECTOR PINOUTS
EPAK Connectors
The PT-VME151A EPAK module interface is comprised of connectors J1, J2, and J3, and the six EPAK
standoffs.
78 Extensible Single Board Computer/Controller User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 15: EPAK Connections
J1
Signal
1
+12
2
-12
3
GND
4
+MPA00
5
+MPA01
6
+MPA02
7
+MPA03
8
+MPA04
9
+MPA05
10
+MPA06
11
+MPA07
12
GND
13
+MPD24
14
+MPD25
15
+MPD26
16
+MPD27
17
+MPD28
18
+MPD29
19
+MPD30
20
+MPD31
21
GND
22
-EPSEL
23
-MPRMC
24
-MPUAS
25
-MPUDS
26
-MPWRT
27
-EPSA0
28
-EPIRQ
29
-EPVIR
30
-EPVIA
31
+EPKIO
32
GND
33
+MPCLK
34
-MPCLK
35
-MPRST
36
-BDRST
J2
Signal
1
+MPSZ0
2
+MPSZ1
3
+MPFC0
4
+MPFC1
5
+MPFC2
6
GND
7
+MPA08
8
+MPA09
9
+MPA10
10
+MPA11
11
+MPA12
12
+MPA13
13
+MPA14
14
+MPA15
15
GND
16
+MPA16
17
+MPA17
18
+MPA18
19
+MPA19
20
+MPA20
21
+MPA21
22
+MPA22
23
+MPA23
24
GND
25
+MPD16
26
+MPD17
27
+MPD18
28
+MPD19
29
+MPD20
30
+MPD21
31
+MPD22
32
+MPD23
33
GND
34
-EPSA1
35
-EPERR
36
+REFCK
J3
Signal
1
+MPA24
2
+MPA25
3
+MPA26
4
+MPA27
5
+MPA28
6
+MPA29
7
+MPA30
8
+MPA31
9
GND
10
+MPD00
11
+MPD01
12
+MPD02
13
+MPD03
14
+MPD04
15
+MPD05
16
+MPD06
17
+MPD07
18
GND
19
+MPD08
20
+MPD09
21
+MPD10
22
+MPD11
23
+MPD12
24
+MPD13
25
+MPD14
26
+MPD15
27
GND
28
-MPSA0
29
-MPSA1
30
-MPBER
31
-MPHLT
32
-EPKPE
33
GND
34
-EPKBR
35
-MPBGA
36
-EPKBG
