5
Section CONNECTOR PINOUTS

VMEbus Pin Assignments

76 Extensible Single Board Computer/Controller User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table 13: VMEbus "P1" Connections

P1A Signal
1 D00
2 D01
3 D02
4 D03
5 D04
6 D05
7 D06
8 D07
9 GND
10 SYSCLK
11 GND
12 DS1*
13 DS0*
14 WRITE*
15 GND
16 DTACK*
17 GND
18 AS*
19 GND
20 IACK*
21 IACKIN*
22 IACKOUT*
23 AM4
24 A07
25 A06
26 A05
27 A04
28 A03
29 A02
30 A01
31 -12V
32 +5V
P1B Signal
1 BBSY*
2 BCLR*
3 ACFAIL*
4 BG0IN*
5 BG0OUT*
6 BG1IN*
7 BG1OUT*
8 BG2IN*
9 BG2OUT*
10 BG3IN*
11 BG3OUT*
12 BR0*
13 BR1*
14 BR2*
15 BR3*
16 AM0
17 AM1
18 AM2
19 AM3
20 GND
21
22
23 GND
24 IRQ7*
25 IRQ6*
26 IRQ5*
27 IRQ4*
28 IRQ3*
29 IRQ2*
30 IRQ1*
31
32 +5V
P1C Signal
1 D08
2 D09
3 D10
4 D11
5 D12
6 D13
7 D14
8 D15
9 GND
10 SYSFAIL*
11 BERR
12 SYSRESET*
13 LWORD*
14 AM5
15 A23
16 A22
17 A21
18 A20
19 A19
20 A18
21 A17
22 A16
23 A15
24 A14
25 A13
26 A12
27 A11
28 A10
29 A09
30 A08
31 +12V
32 +5V
