Section FUNCTIONAL SUMMARY

Interrupt Control

The ACC controls local and VMEbus interrupts. Because the ACC allows the dynamic assignment of
local interrupts to specific request levels, a fixed interrupt map is unnecessary. The following table lists
the internal and VMEbus interrupt sources and the levels to which they may be assigned. The ACC inter-
rupt input pin for each local interrupt request is also shown.
68 Extensible Single Board Computer/Controller User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table 5: Interrupt Request Summary

Interrupt Source
VMEbus IRQ1
VMEbus IRQ2
VMEbus IRQ3
VMEbus IRQ4
VMEbus IRQ5
VMEbus IRQ6
VMEbus IRQ7
Location Monitor
VMEbus Events
Tick & Interval Timer
FAS216 & EPAK [EPIRQ]
EPAK [EPVIR]
68681
Abort Switch
Parity Error & SCSI bus Reset
VMEbus [*ACFAIL]
VMEbus [*SYSFAIL]
Possible Level Assignments
1 (or off) Vectored
2 (or off) Vectored
3 (or off) Vectored
4 (or off) Vectored
5 (or off) Vectored
6 (or off) Vectored
7 (or off) Vectored
1-7 (or off) Auto-Vectored
1-7 (or off) Auto-Vectored
1-7 (or off) Auto-Vectored
1-7 (or off) Auto-Vectored
1-7 (or off) Vectored
1-7 (or off) Vectored
7 (or off) Auto-Vectored
7 (or off) Auto-Vectored
7 (or off) Auto-Vectored
7 (or off) Auto-Vectored
ACC Input
VIRQ1
VIRQ2
VIRQ3
VIRQ4
VIRQ5
VIRQ6
VIRQ7
LIRQ0
LIRQ1
LIRQ2
LIRQ3
LIRQ4
LIRQ5
L7I0
L7I1
L7I2
L7I3
