Removing The Chassis Cover - Supermicro SC836BE1C-R1K23B User Manual

4-3

Removing the Chassis Cover

Release Tab
Removing the Chassis Cover
1. If necessary, unplug the chassis from any power source
2. If necessary, remove the two screws securing the cover to the side of the chassis.
3. Depress the two release buttons, pushing the cover toward the rear of the
chassis, and lift it up and off.
Caution: Except for short periods of time, do not operate the server without the
cover in place. The chassis cover must be in place to allow proper airflow and
prevent overheating.
1
3
Figure 4-2. Removing the Chassis Cover
Chapter 4: Chassis Setup and Maintenance
1
3
1
3
4-3
2
Remove this screw
(if necessary)
