1-1

Overview

Supermicro's SC836 storage chassis supports up to sixteen hot-swappable 3.5"
SAS/SATA hard drives, the industry's highest storage density for a 3U system. The
SC836 includes 100% cooling redundancy and high efficiency (1+1) redundant
power supplies with PM BUS functionality for enhanced power management. The
chassis is optimized for the next-generation dual-processor Intel Xeon (5500 series)
and AMD Opteron platforms. Direct attached HDD backplane (TQ version), multilane
backplane (A version) and expander backplane (E1, E2 versions) are available
for application-specific solution optimization. Heavy duty palletized packaging is
available to ensure secure system reliability during shipping. Tool-less, roller rail
designs for easy installation and maintenance are standard with each system.
Model
SC836BE1C-R1K03B
SC836BE2C-R1K03B
SC836BHA-R1K28B
SC836BHE16-R1K28B
SC836BHE26-R1K28B
SC836BE16-R1K28B
SC836BE26-R1K28B
SC836BA-R1K28B
SC836BE16-R920B
SC836BE26-R920B
SC836BA-R920B
SC836TQ-R500B
SC836E16-R500B
SC836E16-R1200B
SC836E26-R1200B
SC836A-R1200B
SC836TQ-R800V /
SC836TQ-R800B
SC836TQ-R710B
SC836BE1C-R1K23B
Chapter 1
Introduction
SC836 Chassis Series
HDD PCI Slots Power Supply
16x 3.5" SAS
7x FF
2x 2.5" SAS
16x 3.5" SAS
7x FF
(opt) 2x 2.5" SAS
16x 3.5" SAS
7x FF
(opt) 2x 2.5" SAS
16x 3.5" SAS
7x FF
2x 2.5" fixed
16x 3.5" SAS
7x FF
3x 2.5" fixed
16x 3.5" SAS 7x FF
16x 3.5" SAS 7x FF
16x 3.5" SAS
7x FF
(opt) 2x 2.5" SAS
1-1
Chapter 1: Introduction
1000W (Redundant, Titanium)
1280W (Redundant, Platinum)
920W (Redundant, Platinum)
500W (Redundant, Platinum)
1200W (Redundant, Gold)
800W (Redundant)
710W DC (Redundant)
1200W (Redundant, Titanium)
