SC836 Chassis Manual
Overheating
There are several possible responses if the system overheats.
Overheat Temperature Setting
Some backplanes allow the overheat temperature to be set at 45, 50, or 55 by
changing a jumper setting. For more information, consult the backplane user manual
at www.supermicro.com. (Click Support, then the Manuals link.)
Responses
If the server overheats:
1. Use the LEDs to determine the nature of the overheating condition.
2. Confirm that the chassis covers are installed properly.
3. Check the routing of the cables and make sure all fans are present and operating
normally.
4. Verify that the heatsinks are installed properly.
3-4
Drive Carrier LEDs
The chassis includes externally accessible SAS/SATA drives. Each drive carrier
displays two status LEDs on the front of the carrier.
Activity LED
Status LED
LED Color
Blinking Pattern
Blue
Solid On
Blue
Blinking
Red
Solid On
Red
Blinking at 1 Hz
Red
Blinking with two
blinks and one stop
at 1 Hz
Red
On for five
seconds, then off
Red
Blinking at 4 Hz
Behavior for Device
SAS drive installed
I/O activity
Failed drive for SAS/SATA/NVMe
with RSTe support
Rebuild drive for SAS/SATA with
RSTe support
Hot spare for SAS/SATA with
RSTe support
Power on for SAS/SATA with
RSTe support
Identify drive for SAS/SATA with
RSTe support
3-4
