A-3 Extending Power Cables
Some compatible motherboards have power connectors in locations that require
extended power cables. Use the following chart as a guide.
Number of Pins
24-pin
20-pin
8-pin
4-pin
A-4 Front Panel to the Motherboard
The chassis includes a cable to connect the chassis front panel to the motherboard.
If your motherboard uses a different connector, use the following list to find a
compatible cable.
Front Panel to Motherboard Cable (Ribbon Cable)
Number of Pins
(Front Panel)
16-pin
16-pin
20-pin
16-pin
20-pin
* Split cables: Use these cable if your motherboard requires several different
connections from the front panel.
Power Cable Extenders
Cable Part #
CBL-0042
CBL-0059
CBL-0062
CBL-0060
Number of Pins
(Motherboard)
16-pin
20-pin
20-pin
varies
various*
A-5
Appendix A: Chassis Cables
Length
7.9" (20 cm)
7.9" (20 cm)
7.9" (20 cm)
7.9" (20 cm)
Cable Part #
CBL- 049
CBL-0048
CBL-0047
CBL-0068
CBL-0067
