SC836 Chassis Manual
Changing the Power Supply:
1. Unplug the AC cord from the module to be replaced.
2. Push the release tab on the back of the power supply as illustrated.
Release Tab
Figure 4-14. Power Supply Release Tab
3. Pull the power supply out using the handle provided.
4. Replace the failed power module with the same model.
5. Push the new power supply module into the power bay until it clicks.
6. Plug the AC power cord back into the module.
4-14
