SC836 Chassis Manual
836E16
CBL #
-R500B
0084 ●
0157L ●
0044L ●
0082L ●
●
0296L
●
0108L-02
0281L ●
CBL # Description
0071L Front panel, Round 16-pin to 16 Pin Ribbon FP cable 75cm. 28AWG
0088L Fan, 10.5" 4-pin Middle fan power extension (PWM). 24AWG
0180L-01 SATA Cable Set
0087 20" 16-pin to 16-pin Round Ribbon Cable
0078 floppy, 45cm Round Floppy Cable
0139L DVD drive 50cm Cable
0084 Split Front Panel Cable
0157L SGPIO, 8-pin to 8-pin Ribbon Cable for SGPIO (For Additonal Drives)
0044L SATA S-S, 61cm
0082L SATA Power Y Split Adapter
0296L Fan, 4-pin fan extension cord, 9" length
0108L-02 SFF 8087 to SFF 8087 Internal Backplane Cable, 39cm
0281L SFF 8087 to SFF 8087 Internal Backplane Cable, 75cm
836E26
-R1200B -R1200B
***Cables listed below are optional***
● ●
● ●
● ●
● ●
● ●
● ●
● ●
Cable Description by Part Number
836A 836TQ
-R800B/V
● ●
● ●
● ●
● ●
● ●
●
●
A-2
-R710B -R500B
● ●
● ●
● ●
