SC836 Chassis Manual
Front Jumper Locations and Pin Definitions
JP61
Explanation of Jumpers
To modify the operation of the backplane,
jumpers can be used to choose between
optional settings. Jumpers create shorts
between two pins to change the function
of the connector. Pin 1 is identified with
a square solder pad on the printed circuit
board.
Note: On two pin jumpers, "Closed" means
the jumper is on and "Open" means the
jumper is off the pins.
Jumper
Open: Default
JP35
Closed: Reset
Open: Default
JP50
Closed: Reset
JP35
JP50
JP100
JP99
JP98
JP97
Figure A-2. Front Jumpers
General Jumper Settings
Jumper Settings
JP84
JP62
JP63
MG9072 chip reset #1
MG9072 chip reset #2
C-6
JP64
3
2
Connector
Pins
Jumper
3
2
Setting
Note
1
1
