Chapter 4: DVI/VGA Input Interface
Table 4-5: Analog UXGA60 (Continued)
Register Name
Clamp Duration
HSOUT Pulse width

DVI

DVI does not require different settings for different resolutions.
Table 4-6: DVI
Register Name
Active Interface
Mode Control 2

References to VGA, DVI Standards

Official VGA standards are available for purchase from the Video Electronics Standards
Association at: http://www.vesa.org.
DVI specifications are freely available from the Digital Display Working Group at
http://www.ddwg.org.
www.BDTIC.com/XILINX
40
Register Register
Address Value
0x06 0x78 120 cycles in duration
0x07 0xC0 192 cycles in HSYNC
Register Register
Address Value
0x12 0xC1 Force selection of DVI input
0x10 0x74 Set bus to 2 pixels/clock
