SIDE GLASS / SNEEZE GUARD REMOVAL & REPLACEMENT (PAGE #1 of 2)
1. Side Glass Removal
Caution! Hold glass firmly while removing retaining
screws!
A. Remove all four (4) retaining screws.
B. Carefully remove side glass from case.
C. Should replacement be required, replace glass in
reverse order it was removed.
2.A. Lift top
1.A-C. Remove glass up and
side glass off case.
View From Front
2.D Remove
light shield
of Case
2. Sneeze Guard Removal & Replacement
A. Lift top glass up and off (no screws required).
B. Remove light bulb (located under light shield).
C. Remove two (2) screws (one at each end of light
shield.
D. Remove light shield.
See next page for continuation...
2.B. Remove light
bulb (located 2.D Remove
under light shield) light shield
View From Rear
33
2.C Remove (2)
screws (one at each
end of light shield).
of Case
