READ AND SAVE THESE INSTRUCTIONS
INSTALLATION & OPERATING MANUAL
SELF-SERVICE
NON-REFRIGERATED
SCC P/N 99391
BAKERY CASES
CDR5723
HVPF74SS
HVPFRB112
HVP56SS
CDR4694
HVP74.5319
HVP112.4906D
CDR7370
HVP74.4906F
HVP48.5319F
888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
I:\Oper Manuals\Encore\HVP[L]SS_HVPF[L]SS_HVPF112_HVPFLB112_HVPFRB112_4694_5319_5723_99391.pub
Rev W Date: 4.18.2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVP48SS and is the answer not in the manual?

Questions and answers

Summary of Contents for Structural Concepts HVP48SS

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION & OPERATING MANUAL SELF-SERVICE NON-REFRIGERATED SCC P/N 99391 BAKERY CASES CDR5723 HVPF74SS HVPFRB112 HVP56SS CDR4694 HVP74.5319 HVP112.4906D CDR7370 HVP74.4906F HVP48.5319F 888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com I:\Oper Manuals\Encore\HVP[L]SS_HVPF[L]SS_HVPF112_HVPFLB112_HVPFRB112_4694_5319_5723_99391.pub Rev W Date: 4.18.2018...
  • Page 2: Table Of Contents

    TROUBLESHOOTING ………………………………………………………………………………..……….. TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ….…………..This Manual Pertains To The Following Models*: HVP48SS, HVP48.5319F, HVP56SS, HVP74SS, HVP74.4906B, HVP74.4906F, HVP74.5319, HVP112SS, HVP112.4906D, HVPF56SS, HVPF74SS, HVPF112, HVPFLB112, HVPFRB112, CDR4694, CDR5723, and CDR7370 *This Manual May Also Be Applicable To Models Not Listed Above.
  • Page 3: Overview / Type / Compliance / Warnings / Precautions / Plugs / Wiring Diagram

    COMPLIANCE - Performance issues when in violation of OVERVIEW applicable NEC, federal, state and local electrical codes  These Structural Concepts merchandisers are are not covered by warranty. designed to merchandise packaged products at ambient temperatures. WARNINGS - This page contains an important warning to ...
  • Page 4: Installation

    INSTALLATION 1. Remove Unit From Skid 2. Position & Align Case Alongside Other Cases Slide unit to rear of skid and tip backward off skid.  Before adjusting levelers, make certain that the case is in proper position and, if required, aligned with adjoining case(s).
  • Page 5: Installation

    INSTALLATION, CONTINUED 5. Caster Locking / Unlocking Operation Casters In Locked Position  Certain models may have casters to allow ease of transport.  To lock casters (from the unlocked position), press down on RAISED caster levers (as shown in illustration at right).
  • Page 6: Start-Up And Operation, Cont'd: Ballast Box / Electrical Hookup

    START-UP AND OPERATION: BALLAST BOX / ELECTRICAL HOOKUP 1. Ballast Box Access  The ballast box may be located left rear (from the customer front) against the end panel inside the base of the case that contains the Ballast shelves and doors. ...
  • Page 7: Start-Up And Operation, Cont'd: Lights [Standard Vs. Led Lights]

    If case is provided with LED lights, they will rarely require change-out. LED’s Oval Form Plug’s  Contact Structural Concepts’ Technical Service Oval Form Department for replacement parts (see the Technical Service section of operating manual). Replacement of lamp: ...
  • Page 8: Start-Up And Operation, Cont'd: Light Switches [Front]

    START-UP AND OPERATION, CONTINUED: LIGHT SWITCHES [FRONT] - PAGE 1 of 2 Start-Up And Operation, Continued Rocker Switch Warning! Disconnect power before providing maintenance and service to unit. Caution: Lamps have been treated to resist breakage and must be replaced with similarly treated lamps. Note: Warranty will be void if claims arise from negligence, misuse of goods, extreme environmental conditions or improper maintenance.
  • Page 9 START-UP AND OPERATION: LIGHT SWITCHES [FRONT] - PAGE 2 of 2 Start-Up And Operation, Continued Rocker Switch 3. Front Light Switch Accessible Units  Light switch is located on the right front of the unit. Rotate the round cover plate to access the switch. ...
  • Page 10: Start-Up And Operation, Cont'd: Rear Light Switches / Under-Shelf View

    START-UP AND OPERATION, CONT’D: REAR LIGHT SWITCHES / UNDER-SHELF VIEW OF LIGHTS  Start-Up And Operation, Continued First time lighting may require a short warm up period for the bulbs. 1. Under-Shelf View of Lights  Slightly dim or a flickering of new bulbs is normal. ...
  • Page 11: Start-Up And Operation, Cont'd: Model Cdr5723 Lights / Light & Fan

    START-UP AND OPERATION, CONT’D: MODEL CDR5723 LIGHTS / LIGHT SWITCH / FAN SWITCH  Start-Up And Operation, Continued All fans will come on at the same time.  If lights do not turn on, check all of the raceway 1. Under-Shelf View of Lights plugs.
  • Page 12: Start-Up And Operation, Cont'd: Model Cdr5723 Door Holding Mechanism

    START-UP AND OPERATION, CONT’D: MODEL CDR5723 DOOR HOLDING MECHANISM Start-Up And Operation, Continued 2. Door Locks Open When Plunger Pin Is Extended Door Holding Mechanism  Illustration #2 shows plunger pin extended  Doors can be held open for ease of loading (handle lowered to bottom of side slot).
  • Page 13: Maintenance Fundamentals: Shelf Ass'y / Door Actuator / Tissue Box Access

    MAINTENANCE FUNDAMENTALS: SHELF ASSEMBLY / DOOR ACTUATOR / TISSUE BOX ACCESS 1. Shelf Assembly Removal Rear Rack Support  Remove and set aside glass or wire shelves.  For lighted shelving, unplug the light cord and detach from the rear shelf support. ...
  • Page 14: Front Glass Doors / Removing, Emptying & Replacing Trash Bin

    MAINTENANCE FUNDAMENTALS: REMOVING SLIDING REAR & FRONT GLASS DOORS & TRASH 1. Removing the Rear Sliding Glass Doors Rear Note: Doors are not interchangeable. There is an Sliding Glass inner and outer door. The outer must be removed Doors first and replaced last. ...
  • Page 15: Illustrated Parts Breakdown [Model Hvpfrb112 Only]

    ILLUSTRATED PARTS BREAKDOWN [MODEL HVPFRB112 ONLY] Note: Image shown below is for illustration purposes only. It may not reflect your particular case’s features or options. Bin, Acrylic Mirror, End Panel Box, Napkin Bulb Cup, Twist Assembly, Rack Light Panel, End 10 Rack, Wire Assembly, Door Right Hand 11 Support, Rear Rack...
  • Page 16: Illustrated Parts Breakdown [Model Hvp74.5319 Only]

    ILLUSTRATED PARTS BREAKDOWN [MODEL HVP74.5319 ONLY] Curved Clear Front Glass Stainless Steel Rail Bumper Sign Channel (Typical) Stainless Steel Drop-Down Toe-Kick Panel (Typical) Tissue Box Holder (Typical) Side Glass (Typical) Hanging Bag Holder (Typical) 10 Front Glass Door (Typical) Individual Paper Bag Holder (Typical) 11 Flat, Clear Glass Top Flat Box Holder (Typical) 12 Rear Sliding Doors...
  • Page 17: Illustrated Parts Breakdown [Model Cdr5723 Only]

    ILLUSTRATED PARTS BREAKDOWN [MODEL CDR5723 ONLY] Exhaust Fans (Emitting Warm Air From Lights) Bags Shelving (Typical) Deck Pan (Typical) Pans (Typical) Tissue Crumb Tray (Typical) 10 Handles (Typical) Corner Cap (Typical) 11 Doors, Glass (Typical) Toe-Kick (Typical) 12 Tissue Box...
  • Page 18: Illustrated Parts Breakdown [Model Cdr7370 Only]

    ILLUSTRATED PARTS BREAKDOWN [MODEL CDR7370 ONLY] Fans (For Air Circulation) Toe-Kick (Customer-Left) Doors, Glass (Typical) Flip-Down Door To Shelf (Customer-Left) Deck (Typical) 10 Tissue Dispenser Cavity (Typical) Toe-Kick (Customer-Right) 11 Bags/Sacks Dispenser Cavity (Typical) Caster, Locking, at Case Underside (Typical) 12 Hinged Door To Shelves (Typical) Flip-Down Door (Customer-Right) 13 Box Dispenser Cavity (Typical)
  • Page 19: Serial Label Information And Location

    For additional technical information and service, see the TECHNICAL SERVICE page in this  For additional technical information and service, see the TECHNICAL SERVICE page in this manual for instructions on contacting Structural Concepts’ Technical Service Department. manual for instructions on contacting Structural Concepts’ Technical Service Department. ...
  • Page 20: Cleaning Schedule

    CLEANING SCHEDULE Cleaning Daily Weekly Monthly Task The acrylic must be cleaned with a mild soap and Clean Case water solution and a soft cloth. Never use a Exterior household cleaner on acrylic. Rear doors and door track: Remove rear doors and clean with a household or commercial cleaner.
  • Page 21: Troubleshooting

    TROUBLESHOOTING Issue Resolution of Issue Product is Drying Out Check the relative humidity in the store. Case is not Operating Confirm the utility power is on. Check the MAIN power switch is on. If power cord is used, check the unit is properly plugged in. Trained Service Providers Only: Check the circuit breaker box for tripped circuits.
  • Page 22: Technical Service Contact Information & Warranty Information

    LIMITED WARRANTY All sales by Structural Concepts Corporation (SCC) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty Scope: Warranty is for equipment sold in the United States, Canada, Mexico and Puerto Rico. Equipment sold elsewhere may carry modified warranty.
