Harmony® User Manual
P A R T N U M B E R : 2 1 - 3 4 9 8 9
Please Note
Your specific model number is located on the
serial label (usually at the case rear). However,
label locations may vary depending on the
model – see page 20 for more details.
Models shown on this cover sheet do not
represent all models covered by this manual.
Support:
structuralconcepts.com/support
Tech Service/Warranty:
1 (800) 433-9490, EXT. 1
Hours:
Monday – Friday, 8am to 8pm EST (Closed holidays)
21-34989 HARMONY REFRIGERATED CASES MANUAL-EN
Models
HMBC2
HMO6353R
HMBC3
HMO7553R
HMBC4
HMO3936R
HMBC5
HMO5136R
HMBC6
HMO7536R
HMG3953R
HMG5153R
HMG6353R
HMO2653R
HMO3953R
HMO5153R
Before contacting, you must have the following:
Serial no., model no., store no., store address, details (photos, leak locations,
damage, store's ambient conditions, etc.)
HMG3953R
REV B DATE: 10/18/24
