Appendix | Accessories

Appendix

A 1 Accessories
Cable harness/5 m/standard
for surfaceCONTROL
A 2 Optional Accessories
Table power pack
X95/dovetail
mounting adapter
47° dovetail
mounting adapter
Transport case
Calibration target
2D/3D Gateway
surfaceCONTROL 3D SC2500 / SC2510
Cable harness for connecting a sensor to the controller,
contains the cables for data transmission of both cameras
and sensor control;
length 5 m,
total cable diameter: approx. 6.8 mm,
minimum bending radius with continuous movement: 10x
cable diameter.
Table power pack for sensor supply,
input 100-240 VAC 50/60 Hz ~1.8 A,
Output 19 VDC/7.89 A
Adapter for mounting on X95 profile (Qioptiq) or on tripod
head with dovetail
Adapter for mounting on tripod head with dovetail
FlightCase for transporting sensors and accessories
Calibration target for calibrating the sensor
Fieldbus coupler for 2D/3D sensors combined with 3DIn-
spect,
configurable for PROFINET, EtherNet/IP and EtherCAT,
Evaluations from 3DInspect can be transmitted to a PLC via
one of these fieldbus systems,
Sensor settings can be loaded by a controller via 3DInspect
using parameter set mapping,
Page 31
