MICRO-EPSILON surfaceCONTROL SC2500 Operating Instructions Manual page 36

Appendix | GenICam surfaceCONTROL Parameters | Version 1.5
Name
ImageOffset[SourceSelector]
[ComponentSelector]
Acquisition Control
AcquisitionMode
AcquisitionStart
AcquisitionStop
TriggerMode[TriggerSelector]
TriggerSoftware
[TriggerSelector]
TriggerSource
[TriggerSelector]
TriggerActivation
[TriggerSelector]
ExposureTime
PatternDisplay
MultiSlopeMode
MultiSlopeKneePointCount
MultiSlopeKneePointSelector
MultiSlopeExposureLimit
[MultiSlopeKneePointSelector]
surfaceCONTROL 3D SC2500 / SC2510
Description
2D Mode components
only: Offset
Sets the acquisition mode
of the device.
Starts the Acquisition of
the device.
Stops the Acquisition of
the device at the end of
the current Frame.
Controls if the selected
trigger is active.
Generates an internal trig-
ger. TriggerSource must
be set to Software.
Specifies the internal
signal or physical input
Line to use as the trigger
source.
Specifies the activation
mode of the trigger.
Sets the Exposure time in
Microseconds.
Defines the pattern that is
shown during live stream.
Controls multi-slope expo-
sure state.
The number of knee-
points as well as the
number of additional
exposure slopes used for
multi-slope exposure.
Selects the parameters
for controlling an addi-
tional slope in multi-slope
exposure.
Percent of the Expo-
sureTime at a certain
knee-point of multi-slope
exposure.
Documentation Text
Offset for the gray values of the [Amplitude], [Curvature] and [Base]
components.
Sets the mode for 3D image acquisition.
SingleFrame - single measurement, must be stopped using Acquisi-
tionStop) (repeated measurement requires repeated AcquisitionStart).
Continuous - continuous image acquisition (after AcquisitionStart) is
performed until AcquisitionStop occurs.
Starts image acquisition. If TriggerMode = Off, image acquisition starts
immediately. If TriggerMode = On, the system waits for a trigger event.
Stops image acquisition once the current 3D frame has been transmit-
ted in its entirety.
Enables trigger mode.
Command to trigger a measurement.
Source of trigger signal. Available are Software (software trigger using
Genicam command) and Line1 (hardware trigger from Input Line1).
Sets whether the rising or falling slope of the trigger signal (only hard-
ware trigger) is used to trigger a measurement.
The exposure time of the cameras in [µs].
Selects the image to be projected by the projector for live image
operation.
The following entries are available:
- Bright image
- Off
- Fringe pattern
- Positioning aid
