Appendix | GenICam surfaceCONTROL Parameters | Version 1.5
Name
Device Control
DeviceTemperatureSelector
DeviceTemperature
[DeviceTemperatureSelector]
Source Control
SourceSelector
Image Format Control
RegionSelector
Width[SourceSelector]
[RegionSelector]
Height[SourceSelector]
[RegionSelector]
PixelFormat[SourceSelector]
[RegionSelector]
[ComponentSelector]
ComponentSelector
[SourceSelector]
[RegionSelector]
ComponentEnable
[SourceSelector]
[RegionSelector]
[ComponentSelector]
ImageScale[SourceSelector]
[ComponentSelector]
surfaceCONTROL 3D SC2500 / SC2510
Description
Selects the location within
the device, where the
temperature will be mea-
sured.
Device temperature in
degrees Celsius (C).
Selects the source to
control.
Selects the Region of
interest to control.
Width of the image pro-
vided by the device (in
pixels).
Height of the image
provided by the device (in
pixels).
Format of the pixels pro-
vided by the device.
Selects a component to
activate/deactivate its data
streaming.
Controls if the selected
component streaming is
active.
2D Mode components
only: Scale
Documentation Text
Serves as a switch for the temperature sensor to be read:
Internal - internal sensor temperature
Cpu - processor temperature
CpuBoard - temperature of processor's circuit board
LED - LED temperature
CameraSensorBoard1 - internal temperature of camera #1
CameraSensorBoard2 - internal temperature of camera #2
Temperature of the component selected in DeviceTemperatureSelec-
tor.
Serves as a switch for the data source to be configured:
- Source0: Virtual source for 3D measured data
- Source1: Camera 1
- Source2: Camera 2
Serves as a switch for the parameters to describe the measuring field.
Note that this switch also depends on the SourceSelector. The follow-
ing settings are possible:
- Region0: Describes the measuring field of the cameras [Source1] or
[Source2]
- Scan3dExtraction0: Describes the 3D measuring field [Source0]
The number of pixels in u-direction in the camera image [Region0].
For [Scan3dExtraction0] the parameter specifies the number of 3D
points in x-direction.
The following combinations of SourceSelector and RegionSelector are
permissible:
- [Source0][Scan3dExtraction0]
- [Source1/Source2][Region0]
The number of pixels in v-direction in the camera image [Region0].
For [Scan3dExtraction0] the parameter specifies the number of 3D
points in x-direction.
The following combinations of SourceSelector and RegionSelector are
permissible:
- [Source0][Scan3dExtraction0]
- [Source1/Source2][Region0]
Indicates the pixel format used for the selected component. Pixel for-
mats Mono8 and Mono16 are available for the [Intensity] components.
You can select Mono16 or Coord3D_C32f for the 3D data [Range].
The following entries are available:
- Intensity: Live camera image
- Range: 3D data
- Confidence: Mask for invalid points in 3D data
The following combinations of SourceSelector, RegionSelector and
ComponentSelector are permitted:
- [Source0][Scan3dExtraction0][Range]
- [Source0][Scan3dExtraction0][Confidence]
- [Source1/Source2][Region0][Intensity]
Describes the components to be transmitted. It is used in particular
to distinguish between setup operation (live mode) and measurement
mode. Setup operation is enabled, if only the [Intensity] component is
enabled.
Scaling factor for the gray values of the [Amplitude], [Curvature] and
[Base] components.
